Summary of Contents for BluePacket WBT210
-
Page 1: User Manual
WBT210 (Receiver w/ Mic) User Manual Version 1.1 BluePacket Communications, Co.,Ltd. Copyright © 2005. All rights reserved... -
Page 2: Bluetooth Introduction
Bluetooth Introduction Bluetooth is a global wireless standard for enabling short-range wireless connections. It is a simple and instant radio solution that allows different devices to talk to one another. Bluetooth eliminates the need for cables/wires/cords between devices such as mobile phones and headphones. Bluetooth facilitates fast and secure transmissions of both voice and data between devices even if they are not in line-of-sight. -
Page 3: Package List
Package List The following checked items should be in the package. Items Quantity Bluetooth Receiver (RX) Charging Cable headphone WANSTONIC Stereo Devices Thank you for choosing WANSTONIC Stereo Devices. The package includes a Bluetooth receiver & headphone. It is unique and different from most Bluetooth products in the market for its good integration of Advanced Audio Distribution Profile (A2DP), Headset and Handfree Profiles. - Page 4 Bluetooth Receiver Features Superior audio quality - Delivers 44.1 kHz and 48 kHz, 16 bit stereo music (near CD quality audio). Accept / end phone calls – Accept / end phone calls with the button on the receiver. Listen to music and respond to phone calls – Enable switching between music and calls made to your Bluetooth enabled cell phone.
- Page 5 WBT210 Outline Pick up/drop phone(3) Vol DOWN(2) 3.5m/mPhone Jack Micphone Vol UP(1) DC Power I/P Power ON/OFF Figure 1 – Bluetooth Receiver Function Keys Function Button 1 Button 2 Button 3 Mode Phone Mode Volume Up Volume Down Accept / Drop Calls...
-
Page 6: How To Use
How to Use BluePacket Receiver performs well with the Bluetooth TX Dongle and can be used to demonstrate the following usage scenarios: Responding to cell phone Pick up / drop calls made to the receiver from Bluetooth enabled cell phones. Unlike the mono headsets, the Bluetooth receiver can transfer ring/voice to both your ears with two channels. - Page 7 Responding to Cell Phone 1. Setting Up Before you turn on the receiver, please use the charging cable to charge them. 2. Pairing (1) Turn on the Bluetooth enabled cell phone. (2) Turn on the receiver. (3) Operate the Bluetooth enabled cell phone to search the receiver. *Note: Users need to keep the two devices between 2 meters in case of connection failure.
-
Page 8: Turning Off
2. Some cell phones send the ring indication to the receiver while others do not. If your cell phone supports this feature, you should hear the ring tone of your cell phone on the receiver. Phones that do not support ring indication will automatically accept the call. - Page 9 Switching Between Music and Phone Calls 1.Setting Up / Prerequisite Please confirm the receiver has been added to a list of “Paired Device” in the Bluetooth enabled cell phone. Set the Bluetooth TX/HCI dongle to TX mode. *Note: If you haven’t paired the receiver with the Bluetooth enabled cell phone before, you need to refer to the section “Responding to Cell Phone”.
- Page 10 Specification – Bluetooth Receiver Product Name BluePacket Bluetooth Receiver Standard Bluetooth 1.2 compliant Power Class Class 2 Frequency Band 2.402~2.480 GHZ unlicensed ISM band Profile Supported AV, Headset and Hand Free Profiles Audio Format Memory 8M flash external memory Rx Sensitivity <...
-
Page 11: Technical Support
1. Q : How do I know that the battery of the receiver have insufficient power? A : The battery power is almost exhausted when one or more following scenarios happen: (1) The receiver starts to reset automatically. (2) You can constantly hear breaks on the audio link, or (3) You cannot connect the receiver to the TX dongle after several tries. - Page 12 Appendix – Supported Phone List Supported Cell Phones by BluePacket Bluetooth Receiver Brand Nokia Moto Sony Ericsson Siemens Panasonic Dopod 3650 v600 T610 3660 v500 T630 6230 v525 T68i 6820 Z600 7610 A630 K700i* V620 P900 E398 S700 E550 V535...
- Page 13 Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
