Advanipc AES-1210 Series User Manual

Fanless embedded industrial pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

1.

AES‐1210 Series
User Manual

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AES-1210 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Advanipc AES-1210 Series

  • Page 1 AES‐1210 Series User Manual   1   ...
  • Page 2 Advanipc Technology Corporation. Advanipc Technology Corporation reserves all the right in the products described in this manual. No part of this manual may be reproduced or copied without the prior written permission of Advanipc Technology Corporation. Acknowledgements Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp. All other product names or trademarks are properties of their respective owners.
  • Page 3 Before powering up the system, check that the items listed below are included and in good condition. If any item does not accord with the table, please contact your dealer immediately.  AES-1210 series system x 1  Phoenix Terminal Block 2-Pin Female x 1( only for DC input by 2-Pin models) ...
  • Page 4 The equipment does not work well, or you cannot get it to work according to the user manual.  The equipment has been dropped and damaged.  The equipment has obvious signs of breakage. AES-1210 Series User Manual 4   ...

  • Page 5: Table Of Contents

    Contents System Overview ........Chapter 1 System View ....................8 System Bottom Plate ..................9 System Wall Mount Solution ................10 System Dimension ..................11 System Installation ........Chapter 2 How to operate the System ............... 13 2.1.1 DC-IN by 2-Pin Phoenix Connector ............. 13 Figure 2.1.1-1 DC Power Input ............
  • Page 6 3.3.3.6 ACPI Configuration .............. 45 3.3.3.7 USB Configuration ............... 46 3.3.4 Hardware Health Event Monitoring Screen .......... 47 3.3.5 Security Screen ..................48 3.3.6 Boot Screen ..................49 3.3.7 Exit Screen ................... 51 Software Support ..................52 3.4.1 Install Operating System ..............52 3.4.2 Support CD Information ...............

  • Page 7: Chapter 1 System Overview

        Chapter System Overview 7   ...

  • Page 8: System View

    AES-1210 series are with Power Switch, Power LED, HDD LED and 4 USB 2.0 on front bezel. AES-1210 series are with rich I/O. It has DC input by DC-Jack or by 2-pin connector, 2x USB 2.0, Line Out, 2x USB 3.0, 2LAN, dual display VGA/HDMI and Wi-Fi feature by option.

  • Page 9: System Bottom Plate

    System Bottom Plate System equips a bottom plate on the down side of chassis. It is friendly for DRAM, mini-PCIe full-size mSATA module and mini-PCIe half-size devices installation and replacement.     9   ...

  • Page 10: System Wall Mount Solution

    System Wall Mount Solution System equips an optional wall mount bracket to hang AES-1210 on the wall. There are 4 holes from these two wall mount brackets to fix system on the suitable location.   10   ...

  • Page 11: System Dimension

    System Dimension The dimension of AES-1210 is 202mm (W) x 140mm (D) x 30mm (H). 11   ...

  • Page 12: Chapter 2 System Installation

      Chapter     System Installation 12   ...

  • Page 13: How To Operate The System

    How to operate the System 2.1.1 DC-IN by 2-Pin Phoenix Connector System equips a male phoenix 2-Pin terminal block for DC power input. In the accessory box, we provide a female 2-Pin phoenix connector showing as Figure 2.1.1-1. The DC voltage input range is from DC +9V to +36V.

  • Page 14: Optional Dc Power Sources

    2.1.3 Optional DC Power Sources We offer two kind of optional DC power sources for AES-1210 series. One is with 2-Pin phoenix connector which is the most popular for industrial application. Another is with DC-Jack which is the most popular for commodity devices. Both are showed as Figure 2.1.3-1.

  • Page 15: Rs-232 Com Port Connectors

    RS-232 COM Port Connectors System provides two serial ports COM1 and COM2 on front bezel. COM1 supports RS232/422/485 and COM2 supports RS232. COM1 RS‐232/422/485 Pin Description List COM2 RS‐232 Pin Description List  Pin No. RS-232 RS-422 RS-485 1  TX‐ RTX‐  2  3  RTX+  4  RX‐ 5  GND  6  7 ...

  • Page 16: Ethernet Lan Connectors

    Ehernet LAN Connectors System supports two 10/100Mbps Ethernet port by two RJ-45 LAN connectors. USB Ports and Audio System provides 2 x USB 3.0, 2 USB 2.0 type A ports and one line-out audio port on rear I/O. System offers 4 x USB 2.0 type A ports on front bezel.  ...

  • Page 17: Msata And Dram

    mSATA and DRAM System provides friendly SO-DIMM DRAM and mSATA SSD installation, maintenance. SATADOM System provides low profile SATADOM for space limitation. 17   ...

  • Page 18: Chapter 3 Sbc-210 Imb

    Chapter     SBC-210 IMB 18   ...

  • Page 19: Introduction

    Introduction Thank you for purchasing the 3.5” SBC-210, the computing platform of AES-1210 series. In this manual, chapter 3.1 and 3.2 contain introduction of this 3.5” SBC and step-by-step guide to the hardware description. Chapter 3.3 and 3.4 contain the configuration guide to BIOS setup and information of the support CD.

  • Page 20: Specifications

    3.1.1 Specifications Media category provides audio adjust utility for Line, Mic and volume. For some limitation, system provides Line out and volume adjustment only but Mic in. Mic in feature could be implemented by inquiry. CPU    AES‐1210M *AES‐1210E *AES‐1210S  Max. Speed(Core) ...

  • Page 21: Motherboard Layout

    3.1.2 Motherboard Layout   21   ...
  • Page 22 1: Panel Power Selection(PNL_PWR1) 2: Power Input Connector (by 4x1, 2.54” pitch 4-pin box header) 3: Backlight Power Selection (BKT_PWR1) 4: USB 2.0 Headers ( USB0_1, USB2_3, USB4_5) 5: mSATA Selection 6: Inverter Power Control Wafer (BLT_PRW1) 7: SATA2 Connectors (SATAII_1, SATAII_2) 8: Backlight &...

  • Page 23: I/O Panel

    3.1.3 I/O Panel There are two LED next to the LAN port. Please refer to the table below for the LAN port LED   23   ...

  • Page 24: Installation

    Installation This is a 3.5” SBC (5.8” x 4.0”, 148 x 102 mm) form factor IMB (industrial motherboard). Before you install this IMB into AES-1210 chassis, please ensure the I/O of SBC-210 is complete same as AES-1210 chassis I/O. Make sure to unplug the power source before installing or removing the IMB from AES-1210 chassis.

  • Page 25: Installation Of Memory Modules (Dimm)

    3.2.3 Installation of Memory Modules (DIMM) This IMB provides one 204-pin DDR3 (Double Data Rate 3) SO-DIMM slot. Step 1. Align a DIMM (A) on the slot such that the notch (B) on the DIMM matches the break on the slot. Step 2.

  • Page 26: Expansion Slots

    3.2.4 Expansion Slots There is 1 mini-PCIe slot and 1 mini-PCIe/mini-SATA slot on the IMB. Mini-PCIe slot: Mini-PCIe slot, half size is used for PCI Express mini cards. SBC-210 is with “C” and “D” both parts as below figure. Insert the half-size card into the PCI Express Mini Card connector at a slightly upward angle.

  • Page 27: Jumpers Setup

    3.2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on pins, the jumper is “Short”. If no jumper cap is placed on pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when jumper cap is placed on these 2 pins.
  • Page 28     28   ...

  • Page 29: Onboard Headers And Connector

    3.2.6 Onboard Headers and Connectors  29   ...
  • Page 30   30   ...
  • Page 31   31   ...
  • Page 32   32   ...

  • Page 33: Driver Installation Guide

    3.2.7 Driver Installation Guide To install the drivers to your system, please insert the support CD to your optical drive first. Then, the drivers compatible to your system can be auto-detected and listed on the support CD driver page. Please follow the order from top to bottom to install those required drivers.

  • Page 34: Uefi Setup Utility

    UEFI Setup Utility 3.3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2> or <Del> during the Power-On-Self-Test (POST) to enter the UEFI SETUP UTILITY, otherwise, POST will continue with its test routines.

  • Page 35: Navigation Keys

    3.3.1.2 Navigation Keys Please check the following table for the function description of each navigation keys.   35   ...

  • Page 36: Main Screen

    3.3.2 Main Screen When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. DDR3_A1: Memory size of DIMM on SO-DIMM slot System Date: [WEEK MONTH/DAY/YEAR] System Time: [HOUR: MINUTE: SECOND] NOTICE: Please check the system date when you receive the IMB. The system date should be correct because those data were adjusted before shipment.

  • Page 37: Advanced Screen

    3.3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Super I/O Configuration, Chipset Configuration, Storage Configuration, ACPI Configuration, USB Configuration and Voltage Configuration. Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows you to update system UEFI without entering operating systems first like ®...

  • Page 38: Cpu Configuration

    3.3.3.1 CPU Configuration Intel SpeedStep Technology Intel SpeedStep technology is Intel’s new power saving technology. Processors can switch between multiple frequencies and voltage points to enable power saving. The default value is [Disabled]. Configuration options: [Enabled] and [Disabled]. If you install Windows 7/8 and want to enable this function, please set this item to [Enabled].
  • Page 39 Adjacent Cache Line Prefetch Use this item to turn on/off prefetching of adjacent cache lines. Intel Virtualization Technology When this option is set to [Enabled], a VMM (Virtual Machine Architecture) can utilize the additional hardware capabilities provided by Vanderpool Technology. This option will be hidden if the installed CPU does not support Intel Virtualization Technology.

  • Page 40: 3.3.3.2 Chipset Configuration

    3.3.3.2 Chipset Configuration  Share Memory Configure the size of memory that is allocated to the integrated graphics processor when the system boots up Active LVDS Use this to enable or disable the LVDS. The default value is [Enabled]. Panel Type Selection Use this to select panel type. Onboard HD Audio Select [Enabled] or [Disabled] for the onboard HD Audio feature.
  • Page 41 Restore on AC/Power Loss This allows you to set the power state after an unexpected AC/power loss. If [Power Off] is selected, the AC/power resumes off when the power recovers. If [Power On] is selected, the AC/power resumes and the system starts to boot up when the power recovers. The default value is [Last State].

  • Page 42: Storage Configuration

    3.3.3.3 Storage Configuration SATA Controller(s) Use this item to enable or disable the SATA Controller feature SATA Mode Selection Use this select SATA mode. Configuration options: [IDE Mode] and [AHCI Mode]. The default value is [AHCI Mode]. SATA Aggressive Link Power Management Use this item configure SATA Aggressive Link Power Management.

  • Page 43: Intel(R) Smart Connect Technology

    3.3.3.4 Intel(R) Smart Connect Technology Intel(R) Smart Connect Technology Use this item to enable or disable Intel(R) Smart Connect Technology. Intel(R) Smart Connect Technology keeps your e-mail and social networks, such as Twitter, Facebook, etc. updated automatically while the computer is in sleep mode. The default is [Disabled].  ...

  • Page 44: Super I/O Configuration

    3.3.3.5 Super I/O Configuration COM1 Configuration Use this to set parameters of COM1. Select COM1 port type: [RS232], [RS422] or [RS485]. COM2 Configuration Use this to set parameters of COM2. COM3 Configuration Use this to set parameters of COM3. COM4 Configuration Use this to set parameters of COM4.

  • Page 45: Acpi Configuration

    3.3.3.6 ACPI Configuration Suspend to RAM Use this item to select whether to auto-detect or disable the Suspend-to-RAM feature. Select [Auto] will enable this feature if the OS supports it. ACPI HPET Table Use this item to enable or disable ACPI HPET Table. The default value is [Enabled]. Please set this option to [Enabled] if you plan to use this IMB to submit Windows certification.

  • Page 46: Usb Configuration

    3.3.3.7 USB Configuration USB Controller Use this item to enable or disable the use of USB controller. USB 3.0 Controller Use this item to enable or disable the use of USB 3.0 controller. Legacy USB Support Use this option to select legacy support for USB devices. There are four configuration options: [Enable], [Auto], [Disabled] and [UEFI Setup Only].

  • Page 47: Hardware Health Event Monitoring Screen

    3.3.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. CPU_FAN1 Setting This allows you to set CPU_FAN1’s speed.

  • Page 48: Security Screen

    3.3.5 Security Screen In this section, you may set, change or clear the supervisor/user password for the system. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 49: Boot Screen

    3.3.6 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot From Onboard LAN Use this item to enable or disable the Boot From Onboard LAN feature. Setup Prompt Timeout This shows the number of seconds to wait for setup activation key 65535(0XFFFF) means indefinite waiting.
  • Page 50 CSM (Compatibility Support Module) Enable to launch the Compatibility Support Module. Please do not disable unless you’re running a WHCK test. If you are using Windows 8 64-bit and all of your devices support UEFI, you may also disable CSM for faster boot speed. Launch PXE OpROM Policy Select UEFI only to run those that support UEFI option ROM only.

  • Page 51: Exit Screen

    3.3.7 Exit Screen Save Changes and Exit When you select this option, it will pop-out the following message, “Save configuration changed and exit setup?” Select [OK] to save the changed and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, it will pop-out the following message, “Discard changes and exit setup?”...

  • Page 52: Software Support

    3.4.2.4 Contact Information If you need to know more details specification, you may contact your dealer for future information or contact with us by our website at http://www.advanipc.com. 52   ...
