Supersonic IQ-220BT User Manual

IQ-220BT
1. Plug the FM Transmitter into your vehicle's cigarette lighter or power port.
2. Tune your radio to an unused FM frequency, then match the same frequency of this unit.
3. Insert a USB flash drive or SD card that contains MP3 files into the USB port or memory card
slot. It will play and transmit the MP3 files automatically.
4. Line-in Function: Use the provided audio cable to connect an MP3/MP4 player or another
external device to the AUX input of this unit. When using this function, please stop playback
of USB or Memory card, and all functions will be controlled by the external device.
1. Using BT for the first time, you need to pair your mobile phone with this unit. Activate your
mobile phone's BT function, then search for the transmitter signal. When the mobile phone
detects this unit (BT67), please pair and connect by using the original password "0000".
2. In the music playing mode, when there is an incoming call, this unit will automatically switch to
telephone mode. Note: The BT indicator light which is on top of the screen will stop flashing
after the BT signal is connected to your phone/device.
BT Wireless Car Kit
USER GUIDE
KEY FEATURES
• Built-in BT receiver allows you to wirelessly connect
to your BT enabled devices
• Hands-free talk function
• Simultaneously charge 2 portable devices while in use
• Built-in USB input
• Built-in micro SD card reader
• 3.5 auxiliary input
• Built-in microphone
• FM transmitter frequency: 87.5-108 MHz
• LCD display with backlight
• Flexible cable bends into any position
• Remote control
HOW TO USE YOUR FM TRANSMITTER:
HOW TO USE BT FEATURE:
