7
Troubleshooting Tips
•
Make sure the right type of fiber cabling is chosen for
the product you have purchased; single mode and
multi mode fiber operate in entirely different ways
•
CAT5 or higher is recommended for the copper port
cabling
•
Power must be removed before the media converter
is disconnected in hazardous environments for safety
reasons
•
Link Fault Pass Through is disabled by default. When
troubleshooting, set LFPT back to OFF.
•
If only one power supply is connected, the Fault LED
will remain ON. If connecting a second power supply
for redundancy, or connecting Power supply 1 to
Power supply 2, the Fault LED will extinguish.
Document Number: EIR-x-Sx Series_3117qsg
Recommended Accessories
Power Supply –
24 VDC, 1.7 A Output Power,
DIN Rail Mount
# MDR-40-24
1-888-948-2248 | Europe: +353 91 792444
advantech-bb.com
707 Dayton Road | PO Box 1040 | Ottawa, IL 61350
Phone: 815-433-5100 | Fax: 815-433-5109
www.advantech-bb.com | E-mail: support@advantech-bb.com
QUICK START
GUIDE
Model EIR-M-SC,
EIR-M-ST or EIR-S-SC
10/100 to 100 Mbps Ethernet Media Converter
Before you begin, be
sure you have the following:
+ Ethernet Media Converter
+ Panel Mount Bracket
www.advantech-bb.com
Fast and easy on the web:
(EIR-S-SC shown)
Advertisement
Summary of Contents for B+B Sensors EIR-M-SC
-
Page 1: Troubleshooting Tips
ON. If connecting a second power supply for redundancy, or connecting Power supply 1 to Power supply 2, the Fault LED will extinguish. (EIR-S-SC shown) Model EIR-M-SC, Recommended Accessories EIR-M-ST or EIR-S-SC 10/100 to 100 Mbps Ethernet Media Converter Power Supply –... -
Page 2: Hardware Installation
Hardware Installation LED Chart Ports RJ-45 Ports: The RJ-45 ports auto-sense for 10 or 100 State Indication Mbps devices connections. The auto MDI/MDIX feature 1. Select a mounting location and install the switch onto allows connections to switches, workstations and other Power or ports function abnormally a piece of DIN rail or use the included panel mount Steady...
