Creator CROSS-MAX0808 User Manual

Cross series mixed matrix switcher
Hide thumbs
Table of Contents

Advertisement

Quick Links

CREATOR CORPORATION(CHINA)
CROSS
Series
Mixed
Matrix
Switcher
CROSS
Series
Mixed
Matrix
Switcher
User
's
Manual
User
's
Manual
V1.0 Version
CREATOR CORPORATION CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CROSS-MAX0808 and is the answer not in the manual?

Questions and answers

Summary of Contents for Creator CROSS-MAX0808

  • Page 1 CREATOR CORPORATION(CHINA) CROSS Series Mixed Matrix Switcher CROSS Series Mixed Matrix Switcher User Manual User Manual V1.0 Version CREATOR CORPORATION CHINA...
  • Page 2 The meaning of symbols ■Safety instructions For your safe and correct use of equipments, we use a lot of symbols on the equipments and in the manuals, demonstrating the risk of body hurt or possible damage to property for the user or others. Indications and their meanings are as follow.
  • Page 3 Important note ◆This product grounds by the grounding Warning In order to ensure the reliable performance of the wires .To avoid electric shocks, grounding wires equipment and the safety of the user, please and the earth must be linked together. Before the observe the following matters during the process connection of input or output terminal, please of installation, use and maintenance:...
  • Page 4 CREATOR Electronics or local distributors. The copyright of this manual belongs to CREATOR Electronics. Without permission, no unit or individual shall adopt part or all of its content for commercial use.

  • Page 5: Table Of Contents

    1.3 Specifications............................2 1.4 Controller Installation..........................3 1.5 System Connection Diagram....................... 4 Chapter 2 Hardware Description...........................5 2.1 CROSS-MAX0808 Panel View......................5 2.2 CROSS-MAX1616 Panel View......................6 2.3 CROSS-MAX3232 Panel View......................7 2.4 Matrix’s Connection with Peripherals....................9 2.4.1 Input Interface Description......................9 2.4.2 Output Interface Description.....................
  • Page 6 4.2.3 Xin-CAT8 Input Card Function Characteristics..............24 4.2.4 Xin-COMP8 Input Card Function Characteristics............... 24 4.2.5 Xin-SF8 Input Card Function Characteristics..............24 4.3 Output Card............................24 4.3.1 Xout-HDMI8 Output Card Function Characteristics............24 4.3.2 Xout-DVI8 Output Card Function Characteristics...............24 4.3.3 Xout-CAT8 Output Card Function Characteristics..............24 4.3.4 Xout-SF8 Output Card Function Characteristics..............

  • Page 7: Chapter 1 Summary

    CROSS series mixed matrix switcher is a matrix with a variety of remote control devices (such as signal switcher with flexible configuration. With Crestron ,AMX, CREATOR, etc.). high-performance hardware design, it perfectly supports a variety of high-definition digital / 1.1 Equipment...

  • Page 8: Specifications

    32 series Chassis height Input slot Effective number of slots Output slot Xin-HDMI8 Xin-DVI8 Input (maximum signal road Xin-CAT8 number) Xin-COMP8 Xin-SF8 Xout-HDMI8 Xout-DVI8 Output (maximum signal road number) Xout-CAT8 Xout-SF8 Fan assembly card FAN ASSEMBLY CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 9: Controller Installation

    CROSS Series Mixed Matrix Switcher User 's Manual CROSS Series Mixed Matrix Switcher User 's Manual 1.4 Controller Installation The matrix controller uses all metal box ,it can be mounted on a standard19inch cabinet, steps are as follows: CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 10: System Connection Diagram

    CROSS Series Mixed Matrix Switcher User 's Manual CROSS Series Mixed Matrix Switcher User 's Manual 1.5 System Connection Diagram CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 11: Chapter 2 Hardware Description

    CROSS Series Mixed Matrix Switcher User 's Manual CROSS Series Mixed Matrix Switcher User 's Manual Chapter 2 Hardware Description 2.1 CROSS-MAX0808 Panel View front panel: rear panel: CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 12: Cross-Max1616 Panel View

    CROSS Series Mixed Matrix Switcher User 's Manual CROSS Series Mixed Matrix Switcher User 's Manual 2.2 CROSS-MAX1616 Panel View front panel: rear panel: CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 13: Cross-Max3232 Panel View

    CROSS Series Mixed Matrix Switcher User 's Manual CROSS Series Mixed Matrix Switcher User 's Manual 2.3 CROSS-MAX3232 Panel View front panel: CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 14 CROSS Series Mixed Matrix Switcher User 's Manual CROSS Series Mixed Matrix Switcher User 's Manual rear panel: CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 15: Matrix's Connection With Peripherals

    Addition to switch operation by the front panel keys, it also can be used in various control systems (such personal computers, CREATOR control systems, control systems from other manufacturers) to control. 2.4.6 Matrix KEYBOARD Interface 2.4.4 Control Interface of Matrix Matrix provides 1-way KEYBOARD interface,...

  • Page 16: The Connection Between Matrix And Extended Keyboard

    568B standard 568A two ways: standard. 1) Cross-connection Matrix directly connects to control computers via CAT-5 crossover cable. T568A linear order 2)Direct connection method Matrix connects to an Ethernet switcher or hub via CAT-5 straight-through cable. CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 17: The Connection Between Matrix And Computer Signal Input And Output Devices

    T.M.D.S. Data 0- TMDS Data2– T.M.D.S. Data 0+ TMDS Data1+ T.M.D.S. Data 0/5 Shield TMDS Data1 Shield T.M.D.S.Data5- TMDS Data1– T.M.D.S.Data5+ TMDS Data0+ T.M.D.S. Clock Shield TMDS Data0 Shield T.M.D. S. Clock + TMDS Data0– T.M.D.S .Clock- CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 18: Db15 Male Socket Transfer Line (S Terminal, Rca Head)

    (14PIN white power socket corresponds with red switching power supply, ensuring that no problem and black lines). Schematic diagram as follows: will appear in five years. And once failure occurs, it can be replaced fast and conveniently. CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 19 CROSS Series Mixed Matrix Switcher User 's Manual CROSS Series Mixed Matrix Switcher User 's Manual CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 20: Chapter 3 Control Panel Operating Instructions

    CROSS Series Mixed Matrix Switcher User 's Manual CROSS Series Mixed Matrix Switcher User 's Manual Chapter 3 Control Panel Operating Instructions 3.1 Matrix Panel Description CROSS-MAX0808 front panel: CROSS-MAX0808 rear panel: CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 21 CROSS Series Mixed Matrix Switcher User 's Manual CROSS Series Mixed Matrix Switcher User 's Manual CROSS-MAX1616 front panel: CROSS-MAX1616 rear panel: CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 22 CROSS Series Mixed Matrix Switcher User 's Manual CROSS Series Mixed Matrix Switcher User 's Manual CROSS-MAX3232 front panel: CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 23 RS: Separate switch of forward RS-232 and IR channel selection key control signals Signal output channel selection key is used to RECALL:Used in CROSS-MAX0808/1616/3232 select output channel of mixed-signals of audio controller to call the switching status of the preset and video, infrared, and serial, corresponding to group.

  • Page 24: Controller Panel Buttons Instructions

    2 independent RS-232 ports can be used to 3.2.1 Switching Operation Example connect PC or control equipment to realize the central control of system Example: synchronously switch the first channel Ground column. audio and video, and RS-232 and IR control CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 25: Save And Call Operation Example

    Example: synchronously input the audio and At least one serial communication port video, and RS-232 and IR control signal of the current 1st channel, the 3rd and 4th output channels are saved as No. 6, and call. CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 26: Software Startup

    2. Network switcher or router 0x55 3. Internet accessible PC 4. Straight-through cable These system components merely refer to system installation equipment needed by server (matrix controller), the client simply need a computer which can access the Internet. CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 27: Connection Diagram

    For the first time into the TP-link setup interface, it default display status TP-link information, see Figure 2-4 below. Remote control system, TP-link routers only do port mapping settings, i.e. forwarding rules (common routers have this feature). Figure 2-6 Figure 2-7 Figure 2-4 CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 28 TCP Client connection, fill in the IP address (i.e. the IP of public network connected by the matrix controller,), port number (i.e. the port number of matrix controller). After the successful setting, you can realize remote control of the matrix. CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 29: Chapter 4 Input, Output Card Instructions

     Is compatible with the HDMI1.4 standard,  Is compatible with the HDMI1.4 standard, HDCP1.3 protocol, DVI1.0 protocol; HDCP1.3 protocol, DVI1.0 protocol;  Maximum support resolution:  Maximum support resolution: HDPC: 1920x1200P@60_24bit; HDPC: 1920x1200P@60_24bit; HDTV: 1920x1080P@60_36bit. HDTV: 1920x1080P@60_36bit; CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 30: Xin-Cat8 Input Card Function Characteristics

     The longest input distance is up to 7M; Characteristics  Is compatible with the HDMI1.4 standard, HDCP1.3 protocol, DVI1.0 protocol;  Blank card is used to fill the blank missing  Maximum support resolution: audio video input output card HDPC: 1920x1200P@60_24bit; installation. HDTV:1920x1080P@60_36bit. CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 31: Pb-900 Power Supply Box Function Characteristics

    Maximum 5nS(±1nS) transmission delay Interface 8 DVI-D female interface / card Signal strength T.M.D.S. +/- 0.4Vpp Minimum / maximum T.M.D.S. 2.9V/3.3V level Impedance 50 Ω EDID Optional default EDID load function Maximum DC offset 15mV error CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 32 Maximum 5nS(±1nS) transmission delay Interface 8 HDMI-A female interface / card Signal strength T.M.D.S. +/- 0.4Vpp Minimum / maximum T.M.D.S. 2.9V/3.3V level Impedance 50 Ω EDID Optional default EDID load function Maximum DC offset 15mV error CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 33 (recommended the1600x1200@60 (recommended output distance the use of certified HDMI special wire. the use of certified HDMI special wire. Such as Molex TM wire) Such as Molex TM wire) Weight About 0.5KG About 0.5KG CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 34 Model Xin-COMP8 Specifications Interface HD-15 Interface Composite Component Signal type Y/C video VGA video video CV video YPbPr Gain 0 dB 0 dB 150MHz @ 350MHz @ -3dB 380 MHz bandwidth 150MHz @ -3dB -3dB CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 35 The baud rate and Baud rate: 9600, data bits: 8,stop bit : 1, no parity protocol The serial control port 2 = TX,3 = RX,5 = GND structure KEYBOARD control KEYBOARD control 4 bit 3.8mm Phoenix interface CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 36 About 5.3KG(without any About About 19KG(without any Weight card) 9.0KG(without card) card) Maximum power 107W 208W 383W dissipation(studded with maximum power IO card) Mean time between 30,000 hours failures Warranty 1 year free warranty, life-long maintenance CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...

  • Page 37: Chapter 5 Instruction Sets

    Audio and video input [X1] connected to audio AV:[X1]->[ Y1] and video output [Y1] serial Input port / infrared [X1]W[Y1]. RS:[RX1]->[TY1] 1W1. receiving channel [RX1] connected to the serial IR:[RX1]->[TY1] output port/ infrared transmitting channel CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 38 1V1,2,3. ,[Yn]. … output [Y1],[Y2],…,[Yn] AV:[X1]-> [Yn] AV:[X1]-> [Y1] One-way audio video input[X1] [X1]A[Y1],[Y2],… AV:[X1]-> [Y2] connected to the multi-channel audio and video 1A1,2,3. ,[Yn]. … output [Y1],[Y2],…,[Yn] AV:[X1]-> [Yn] CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 39 1~R1,2,3. X2],…,[TXn]. … port[TX1],[TX2],…,[TXn] (RS232 reverse ~RS:[RY1]->[TXn] channel switching) One-way infrared receiving channel output ~IR:[RY1]->[TX1] [RY1]~Q[TX1],[T port[RY1] connected to the multi-channel ~IR:[RY1]->[TX2] 1~Q1,2,3. X2],…,[TXn]. infrared transmitting channel input port … [TX1] ,[TX2],…,[TXn](IR reverse channel ~IR:[RY1]->[TXn] CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 40 / infrared transmitting channel [TXn] Note: All the switching instructions can be sent in multi-items and multi-types at the same time, such as (1V1.1R1.1Q2.2~R1.), matrix will first cache and then execute one by one CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 41 Disconnect one-way audio and video output [Y1]$. B:OFF->[Y1]! [Y1] Quickly disconnect multiplex connections B:OFF->[Y1]! [Y1],[Y2],…,[Y Disconnect multiplex audio and video output B:OFF->[Y2]! 1,2,3$. n]$. [Y1],[Y2],…,[Yn] … B:OFF->[Yn]! [TY1],[TY2],…, Disconnect multi-channel serial output port RS:OFF->[TY1]! 1,2,3R$. [TYn]R$. [TY1],[TY2],…,[TYn] RS:OFF->[TY2]! CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 42 Disconnect multi-channel serial Input port / RS:OFF->[TX2]! [TX1],[TX2],…, infrared transmitting channel IR:OFF->[TX2]! 1,2,3~T$. [TXn]~T$. [TX1],[TX2],…,[TXn] … RS:OFF->[TXn]! IR:OFF->[TXn]! Disconnect all audio and video[Yn] and All$. serial input/output port / nfrared transmitting All A/V/R/I Closed. All$. channel [TXn],[TYn] CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 43 ~IR:[RYn]->[TXn] … A:[X1]->[Yn] V:[X1]->[Yn] … A:[X2]->[Yn] Inquire connection status of all audio and Status. V:[X2]->[Yn] Status. video output … A:[Xn]->[Yn] V:[Xn]->[Yn] … Inquire connection status of all bidirectional RS:[RX1]->[TYn] Inquire. serial / infrared channels IR:[RX1]->[TYn] Inquire. CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 44 (Computer to the matrix) /%Lock; Lock the control panel keyboard System Locked! /%Lock; /%Unlock; Unlock the control panel keyboard System Unlocked! /%Unlock; Note: the panel can be locked or unlocked only by serial command. System Settings instructions CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 45 V: [X2]!>[Yn] ! 2],…[Xn]. output from which output channel … A: [Xn]!>[Yn] ! V: [Xn]!>[Yn] ! … EliminateH[X1] Cancel the corresponding output AV:[X1] EliminateH1 , [X2],…[Xn]. inhibition of audio and video input InputEliminateForbidOK! ,2,3. CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 46 [255]. [255]. [0]> mask 5].[0] <# SHAR 0x[00]. Set network hardware 0x[00]. 0x[11]. 0x[22]. 0x[11]. 0x[22]. address (network <#SHAR0x00.0x11.0x22.0x33. [0x33]. [0x44]. [0x33]. [0x44]. hardware address 16 0x44.0x55> [0x55]> [0x55]> hex) Restore the default <#NETDEFAULT> NETDEFAULT:[OK] <#NETDEFAULT> network configuration CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 47 Read the monitor EDID connected to port [Y1] to the input port [X1], [X2],... , [Xn]. [Y1]D[X1], EDID-OK!( success) When the output port [Y1] equals 0,it 1D1,2,3,8. [X2],…[Xn]. EDID-FAIL!(Failure) means that restores the default EDID to the corresponding input port CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 48 Exit component card debugging mode state Command OK! EXITSET. COMP8 card commands - video switching operation instruction 01C02. Set the active port to CV video mode Command OK! 01C02. 03C02. Set the active port to YPbPr video mode Command OK! 03C02. CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 49 Automatically adjust the screen settings Command OK! 07C15. 08C15. Automatically adjust function enable Command OK! 08C15. 09C15. Automatically adjust function inhibition Command OK! 09C15. Adjust brightness parameter xxC21. Command OK! xxC21. (00<=xx<=99) xxC22. Adjust contrast parameter Command OK! xxC22. CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 50 3.NO matter forward or reverse switch of infrared and serial signal, one way can be switched to another or more ways, multiple ways cannot be switched at the same time to one way. CREATOR CHINA 2013-08 WWW.CREATOR1997.COM...
  • Page 51 CREATOR CORPORATION(CHINA) Copyright by CREATOR Last Revision:08/2013...
