Switch Mode
Multi-Stage Smart

BATTERY CHARGER

GPSC-12-15A
GPSC-12-20A
GPSC-12-40A
OPERATION
MANUAL

SPECIFICATIONS

MODELS GPSC-012-15A
INPUT VOLTAGE
100~120V / 200~23 0V 85~135VAC / 170~270VAC 50/60Hz
OUTPUT VOLTAGE
charge 14.2V for Gel (maintenance free battery)
st
1 stage - Bulk
charge 14.4V for Flooded battery (wet battery)
nd charge 14.2V ~ 14.4V current limited
2 stage - Absorption
rd
3 stage - Float
OUTPUT
DC output current 15A max.
DC output ripple
Line regulation
Load regulation 1.5% @ output current = no load ~ full load
EFFICIENCY
Half load
Full load
PROTECTION
Current limiting
Output short circuit
Battery reverse polarity
Input EMI filter and surge
Output loading with
isolator
Input isolated
PHYSICAL
Cooling fan No
Weight 1.7kg
3.74 lbs
200 x 215 x 80
Size(mm) L x W x H
8 3/8" x 8" x 3 "
Specifications subject to change without notice.
GPSC -012-20A GPSC-012-40A
charge 13.6V
20A max. 40A max.
<50mA @full load
0.1% @ input voltage range
88%
86%
Yes
Yes
DC fuse
Yes
Yes
Yes
Yes Yes
1.9kg 2.8kg
4.18lbs 6.16lbs
240 x 235 x 80
Battery Conection
DC OUTPUT
+ +
