HeroSpeed RT811 series Quick Operation Manual

Installation Precautions

To ensure the normal operation and service life of the switch, observe the following
precautions.
Please install it in a well-ventilated room. Do not block the vents of the equipment.
Do not place and install the switch in direct sunlight or near a heating device.
Allow enough space (more than 10cm) to allow the device to dissipate heat properly.
Do not install the device in a place exposed to moisture, dust, or soot.
Please keep the equipment horizontally installed or installed in a stable place, and
take care to prevent the product from falling.
Do not place heavy objects on the device.
Do not dribble or spill liquid on the device, and ensure that no liquid filled items
can be placed on the device to prevent liquid from flowing into the device.
The interface cables of the device must be routed indoors and outdoors cables
must not be routed to prevent overvoltage and overcurrent caused by lightning.
Please use the power adapter supplied with the product. Do not use other
non-supported products. The grid voltage must meet the input voltage range of
the dedicated power adapter.
Do not disassemble the device at will.
Please transport, use and store the equipment within the allowable humidity and
temperature range.

Connection cable

① Connect one end of the network cable to the switch port and the other end to a
computer or other network device.
Note: Please connect all the computers or network devices to be connected to the
switch before connecting the power adapter.
② Connect the supplied power cord and adapter. Connect the other end of the
adapter to the switch and plug it into an external AC power outlet.
③ Power on the device connected to the switch. The corresponding indicator will light
up. The installation is complete.

Specifications

Item RT812 Series description RT811 Series description
Input：110-240V/AC 50-60Hz 5
Power Adapter
Output：48V-52V/DC
Voltage
Power
Overload protection 100W
Mould：+-4KV
Protection level Differential mode：+-1KV
1~8 port: :10/100Mbps PoE Ethernet LAN port.
Network Port
WAN1/WAN2 port : WAN port:
Network Port 10/100/1000Mbps 10/100Mbps
Ethernet WAN port Ethernet WAN port
Transmission
Network
1~8 口: 100m 1~8 口: 100m
Connector Distance
4
Transmission
Distance
Transmission
Medium
Network
Standard
Network
Switch Maximum
Frame Size
MAC address list
Backplane
bandwidth
PoE
Standard
PoE Power
Supply Type
Power Over
Ethernet
PoE Power
Consumption
PoE Ethernet
LED Status
Indicator
Working
temperature
Storage
temperature
Environmental
Working
humidity
Storage
humidity
Dimension
(L x W x H)
mm
Mechanical
Material
Color
Stability MTBF
RT412 Series description
60W
1~4 口 :10/100Mbps PoE
Ethernet LAN port.
WANport:10/100Mbps
Ethernet WAN port
1~4 口: 100m
Extend switch is default OFF
state（1~4 port）：100m
WAN: 100m
WAN1/WAN2 port: 100m Extend switch is ON
state:(1~4 port:): 250m
Cat5/5e/6 standard network cable
IEEE802.3/10BASE-T
IEEE802.3u/100BASE-TX
IEEE802.3x Flow Control
IEEE802.3x Flow Control, IEEE802.3az
IEEE802.3af
1536 Bytes
2K
1Gbps
IEEE802.3af/at IEEE802.3af
End-Span(4/5+;7/8-)
af,at Adaptive (every port)
When the PoE power supply
When the PoE is powered, 1-8 LEDs are green
is used, 1-4 LEDs are green
1-4 ports are yellow when
When accessing Ethernet, ports 1-8 are yellow
Ethernet is connected
0℃~55℃
-40℃~70℃
10%-90% non-condensing
5%-95% non-condensing
200*118*40 197*73.5*29 132*66*32
SECC
Dark grey
>30000h
5
POE
Quick Operation Guide
Power over Ethernet Switch
RT812 series
RT811 series
RT412 series
Thank you for using our PoE Switch products, please read this manual carefully before use.
Related tools and documents of products, please download from www.herospeed.net.
