Performance Functions and Effects

Performance Features

D Beam Controller

The D Beam controller can be used simply by waving your
hand over it. Depending on the function that is assigned to it,
the D Beam controller can be used to apply varius effects and
to modify the sounds.
1. Press the [PITCH], [FILTER] or [VOLUME] button in the D
BEAM section (the button you press lights blue).
You can't use these buttons at the same time.
Button
Lets you change the pitch of the sounds
PITCH
you play on the keyboard.
Changes the tonal character of the
sounds you play n the keyboard. (For
FILTER
some sounds the timbre change may be
difficult to notice.)
Changes the volume of the sounds you
VOLUME
play on the keyboard.
2. While you play the keyboard to produce sound, place
your hand above the D Beam controller and move it slowly
up and down.
The button you pressed in step (1) above flashes.
3. To turn off the D Beam controller, once again press the
button you pressed in step (1) so the indicator goes out.
34
Explanation
The usable range of the D Beam controller
The diagram shows the usable range of
the D Beam controller. Waving your
hand outside this range will produce no
effect.
The usable range of the D Beam
controller will become extremely small when used under
strong direct sunlight. Please be aware of this when using
the D Beam controller outside.
The sensitivity of the D Beam controller will change depending
on the amount of light in the vicinity of the unit. If it does not
function as you expect, adjust the D Beam Sens parameter as
appropriate for the brightness of your location. Increase this
value will raise the sensitivity (p. 46).
Assigning a function to the D Beam
controller
1. Press and hold the [FILTER] or [VOLUME] button.
The D BEAM screen will appear.
2. Use [ ] [ ] to select a parameter.
3. Turn the VALUE dial to select the desired D Beam function.
4. When you've finished making settings, press [EXIT].
The Main screen will appear.
These settings are system parameters (p. 45).
Functions that can be assigned
D Beam
function
A snare drum roll will continue as long as your
hand is positioned over the D Beam. Move your
DRUM
ROLL*
hand closer to increase the volume, and move
your hand rapidly away to play a cymbal.
Chimes will sound when you position your hand
CHIMES*
above the D Beam. The volume is greater when
you move your hand more rapidly.
The sound of bubbles will continue as long as
your hand is positioned above the D Beam. The
BUBBLE*
volume will increase as you move your hand
closer.
