Summary of Contents for MYSAir MS20
- Page 1 ® Sistema Zonas USER MANUAL MS20 / MS22 / MS25 Sistema Zonas...
- Page 2 INDEX Precautions and stardards MS20 / MS22 y MS25. Installation MS20 / MS22 y MS25. Functions MS22. www.mysair.es...
- Page 3 You must deliver your dialer if remplaced by another, or disposed of at an dedicated collection. Breaching these enviroumental measures are subject to sanctions established by the law on protection enviroument. MATERIALES Y SOPORTES IND. DEL LEVANTE, S.L. C/ Mayor 27, 30149. MURCIA (ESPAÑA) Telf: + 34 966744473 FAX: + 34 966741928 www.mysair.es www.agfri.com www.mysair.es...
- Page 4 INSTALLATION MS20, MS22 y MS25 RECOMENDED LOCATION ON WALL For proper work of the thermostat, it must be installed considering the following recomendations: A) Do not place near a heat or cold source. B) Do not place near a heat or cold current.
- Page 5 FEATURES MS20 Backlit tactile thermostat with hourly programming MS20. Wireless comunication or Cable (RF or CABLE). Ÿ Multiprogramming hourly or manual control. Ÿ Two instalation posibilities, fixed on wall (RF or CABLE) or desktop installed with base (RF). Ÿ Customizable “Sleep” function.
-
Page 6: Setting Time And Date
The thermostat will automatically display the day number of the week it is in after Sistema Zonas Sistema Zonas adjusting the date.. To set time automatically in other MS20 thermostats (Only WiFi model) . More info in: www.mysair.es -> Videos. www.mysair.es... -
Page 7: Hourly Programming
FUNCTIONS MS20 5 - TIMER. This function it´s for timer or countdown to OFF thermostat. Sistema Zonas Sistema Zonas TIMER TIMER PROG The thermostat have this timed cycles: 30/60/90/120 minutes. To set up this function, press icon in some working mode or diretly in “Functions menu”. - Page 8 FUNCTIONS MS20 8 - SPEED FAN FUNCTION. 5 Seconds. WARNING. THIS FUNCTION CAN NOT BE USED IF THE INSTALLATION DOES NOT HAVE THE TOTAL CONTROL MODULE GANGWAY AND THE THERMOSTAT Sistema Zonas IS NOT CONFIGURED FOR THAT. TIMER PROG With termostat off, press icon, or if the thermostat is at rest, press anywhere on display to acces “functions menu”.
- Page 9 FUNCTIONS MS20 Only underfloor refreshing. Only underfloor heating. Sistema Zonas Thermostat off, grill closed. The remaining minutes are also displayed for the thermostat to turn off automatically when the timer is running. Speed Fan. Automatic. Sistema Zonas Fan speed fixed.
- Page 10 Turn On / Turn Off. Working mode selecction. Temperature probe. Temperature Adjustement -0.5ºC. Temperature Adjustement +0.5ºC. Current working area / Indicate Transmit estate Ed, rd, CC..Room Temperature. Actual Working mode*. *Underfloor heating mode will only work when there is radiant stage installation. www.mysair.es...
- Page 11 NOTE1: Only the thermostat from which the system has been started will start up or open the zone. NOTE2: The radio thermostats that would have been in operation during the “Total System Stop” will remain at rest but with the zone closed. www.mysair.es...
- Page 12 Grill closed by setpoint. Change thermostat to heating working mode. Change thermostat to cooling working mode. The display show the thermostat zone every time it starts. Total System Stop. Starting thermostat. The display show the room temperature and setpoint temperature. www.mysair.es...
- Page 13 Room Temperature. Turn ON / Turn OFF. Current working zone Nº Timer(30/60/90/120). Timer time /“OFF” indicator. Working mode*. Working mode key. Temperature adjustement -0.5ºC. Temperature adjustement +0.5ºC. * Underfloor mode will only work when exist a radiant stage installation. www.mysair.es...
- Page 14 NOTE1: Only the thermostat from which the system has been started will start up or open the zone. NOTE2: The radio thermostats that would have been in operation during the “Total system stop” will remain at rest but with the zone closed. www.mysair.es...
- Page 15 Change thermostat to cooling working mode. Low battery, change battery (Only Radio). The remaining minutes are also displayed for the thermostat to turn off automatically when the timer is running. Executing “Total system stop”. The display show the room temperature and setpoint temperature. www.mysair.es...
-
Page 16: General Terms Of Warranty
This document reflects the General Terms of Warranties. For more information you can order the complete warranty policy document at agfri@agfri.com. www.mysair.es... - Page 17 MATERIALES Y SOPORTES IND. DEL LEVANTE, S.L. C/ Mayor 27, 30149. MURCIA (ESPAÑA) Telf: + 34 966744473 FAX: + 34 966741928 www.mysair.es www.agfri.com...
