INSTALLATION INSTRUCTION FOR SR220-250P SERIES SOLAR MODULE
230W series solar modules are made of 60pcs of 156mm×156mm crystalline solar cells in series with high efficiency,
high transmission and low iron toughened glasses , anti-aging EVA and high flame-resistant back sheet to laminate,
and anodized aluminum alloy frame. Products have high efficiency, lifespan easy installation, high wind resistance
etc.
Products are made according to national standard GB/T9535-2005（IEC61215-2005）and have passed authority test
center's examination. Our products can be used in home roof solar systems, PV stations, communication stations,
petrol, ocean, meteorological, traffic and solar building etc.
SR220-250P series solar modules mainly include220W、225W 、230W 、235W、240W、245W、250W
1、Electrical Specification POLY-Si series
Model
Number of cells(pcs)
Pmpp(W)
Voc(V)
Isc(A)
Vmpp(V)
Impp(A)
Max series fuse rating(A)
Nominal Mass
Package Size
Cell Size
MAX
System voltage
Bypass Diode Rating
● The electrical characteristics are within ±10 percent of the indicated values of Isc, Voc and Pmp under test
conditions (irradiance of 100 MW/cm
● Under normal conditions, a photovoltaic module is likely to experience conditions that produce more current
and/or voltage than reported at standard test conditions. Accordingly, the values of Isc and Voc marked on this module
should be multiplied by a factor of 1.56 when determining component voltage ratings, conductor ampacity, fuse sizes,
Mounting Manual
PHOTOVOLTAIC MODULE
2
,AM1.5 spectrum, and a cell temperature of 25℃)
SR220-250P
60
230±3%
38.0±3%
8.18±3%
30.4±3%
7.57±3%
15±3%
21.5kg
1650mm×992mm×50mm
156mm×156mm
DC1000V
45V, 12A,6pcs provided
