Remote Socket Set 5-Pack
A. Function
1. LED on the transmitter (remote control) indicates that a signal is being transmitted.
2. Indicator light on the receiver (socket) indicates that the socket is working.
3. Both transmitter (remote control) and receiver (socket) have 4 channels and 4 codes.
4. The code of the transmitter (remote control) and receiver (socket) can be adjusted.
B. The Product:
1
2
No.
Description
1
LED light
2
ON/OFF Channels
3
LED light
C. Code and Channel Adjustment
1. Code adjustment:
Adjust the code of the transmitter and receiver so that they each use the same code (There are 4
corresponding codes). Please refer to the images below:
Instruction Manual
Order Code: N38HN
3
4
5
6
No.
Description
4
Code adjustment switch
5
LED light
6
Battery cover
Ⅱ
7
Ⅰ
Ⅲ
Ⅳ
2
8
1
3
4
9
No.
Description
7
Code adjustment dial
8
Channel adjustment dial
9
Plug
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Maplin N38HN
Summary of Contents for Maplin N38HN
- Page 1 Instruction Manual Remote Socket Set 5-Pack Order Code: N38HN A. Function 1. LED on the transmitter (remote control) indicates that a signal is being transmitted. 2. Indicator light on the receiver (socket) indicates that the socket is working. 3. Both transmitter (remote control) and receiver (socket) have 4 channels and 4 codes.
- Page 2 2. Channel adjustment: Adjust the channel of receiver to the corresponding channel of the transmitter, please see the following images: there are 4 corresponding channels PS: Please change the code if you encounter interference with another socket. D. Operation: 1．Adjust the code of both transmitter and receiver so that they are using the same code. 2．Adjust the channel of the receiver to the corresponding channel of the transmitter.
