La Crosse TX60U-IT Product Overview Manual

PRODUCT OVERVIEW GUIDE
WIRELESS REMOTE TEMPERATURE/HUMIDITY MONITOR
(With or Without Optional Temperature Probe)
IMPORTANT
This document provides general product information and
specifications. Please visit
complete set up and activation instructions.
First, create an account at www.lacrossealerts.com. Once
you have an account, choose model
to begin the set up process with step-by-step instructions.
Enter the key from the ACTIVATION KEY CARD (included in
the package) when prompted by the website.
Need help? Visit:
http://www.lacrossetechnology.com/support/alerts/
GENERAL USE AND APPLICATIONS
Use your smartphone, tablet or computer to remotely monitor
ambient temperature and humidity levels that affect your home
second home, office or rental property.* The 6 foot detachable
dry probe measures temperature of air outside through a
window, or even in your refrigerator or freezer.* Text & e-mail
alerts can signify power outages to help you protect property or
prevent frozen pipes.* More
MONITORING OPTIONS
•
Home, second home, office or rental property
•
Indoor or outdoor temperature and humidity
•
Basement, garage, attic and utility room
•
Refrigerators, freezers and dry food storage
•
Plants, gardens and greenhouses
•
Outdoor pets, farms and livestock
•
Books, photos and musical instruments
•
Computers, servers and electronics
•
Wine storage and humidors
•
Fireplace mantel
PACKAGE CONTENTS
**Optional external temp.
(1) probe included in select
(2)
packages.
HARDWARE:
1. Wireless Ambient Temperature and Humidity
Monitor with mounting bracket (TX60U-IT)
2. **Optional temperature probe
3. Internet Gateway with mounting bracket,
AC adapter and LAN cable
4. Mounting hardware (screws and drywall anchors)
www.lacrossealerts.com
TX60U-IT
on the website
information.
(3)
on 6 Ft. detachable cable
PRINTED MATERIALS:
5. Printed Product Overview Guide (this document)
IMPORTANT: Product set up and activation
instructions are online:
IMPORTANT: Activation Key Card
6.
set up & activation of every device. Do not throw away.
ADDITIONAL EQUIPMENT (NOT INCLUDED)
• Two fresh AAA, IEC LR03, 1.5V Alkaline batteries
• Two-sided tape as needed
• Browser with high speed Internet
• Network router
for
FEATURES AND MEASUREMENTS (Diagram 1)
(A)
LCD
Button
(B) **Optional external
temp. probe included
in select packages.
(A) Wireless Ambient Temperature & Humidity Monitor:
•
LCD displays ambient air temp. & humidity (CH1)
•
LCD displays probe temperature (CH2)
•
Transmits collected data to Internet Gateway
within a 200 Ft. wireless range.
•
Weather resistant case (not water proof)
Note: The case with LCD cannot get wet and
may be affected by high humidity conditions.
•
Wall hanging or free standing
(B) **Optional Temp. Probe on 6 Ft. Detachable Cable:
•
Wet & Dry temperature probes are sold separately.
Check your retailer for availability. Attach a probe at
any time with no need to reset sensor.
•
**Attach a dry temperature probe to the main sensor
case to monitor DRY environments such as air or dry
soil.
•
**Or attach a Wet probe for measuring wet or humid
conditions such as a pool, aquarium or terrarium:
MODEL #:
•
The wireless sensor transmits temp. & humidity data to the
Internet Gateway (200 Ft. [60.96m] wireless range).*
•
The Internet Gateway connects to your existing network
router and uses your high-speed Internet connection to
upload collected measurements to your own account at
www.lacrossealerts.com.*
•
Once the sensor and gateway are activated on your
account, you can monitor sensor(s) online from a
smartphone, tablet or computer, and set up custom
e-mail/text alerts*.
•
Add up to 5 sensors
Internet gateway to monitor additional areas.
www.lacrossealerts.com
MODEL #: D000.101.BG
D000.102.BG or D000.103.BG
HOW IT WORKS
(sold separately) per
is required for
This socket is ONLY
for the external probe.
DO NOT insert
power plug into it.
