IXIUM 808 Custom Manual

Custom Manuals
Thank you for purchasing an 808 Car Key Micro Camera from WeCostLess.co.uk. Below you will find
instructions for using the cameras controls and general information about the function of the device. If you
have any questions that are not answered here don't forget you can contact us by visiting eBay and sending
us a message!
1. Device Power On/Off
Press and hold button (1) to turn device on. Light illuminates to indicate device is ON.
Press and hold again to turn device off. Light goes out to indicate device is OFF.

2. Video/Photo Capture Button

Photos:
After turning the unit on, the light is illuminated to indicate device is ready for use. Press button (2)
to take a photo. The light will momentarily go out to indicate the photograph has been taken and
then come back on. Each Press will take another photograph.
Videos:
After turning the unit on, the light is illuminated to indicate the device is ready for use. Press and
hold button (2) to begin video recording. The LIGHT FLASHES 3 TIMES AND THEN GOES OUT
to indicate that the device is recording. The Device will continue recording until button (2) is
pressed once to stop recording. The Light comes back on to indicate recording has stopped.
If left recording, the device will continue until the memory card is full, the battery runs out, or
button (2) is pressed.

3. Microphone

The Microphone is used for recording audio during video capture. Do not obstruct or the sound
quality will be significantly reduced.

4. Camera Pinhole

Pinhole recess for camera lens. Be sure to keep clean and unobstructed for maximum clarity in your
video captures.

5. Indicator Light

Light indicates device status.
On Charge:
In Use:
6. Mini USB Charging Socket & Charging The Device
Mini USB charging socket for use with the included Mini USB charging cable connected to a desktop
808 Car keys Micro Camera
720 x 480 Video recording at 30FPS
1280 x 960 Photo Resolution
Yellow light on solid (full charge approximately two hours).
Waiting = yellow light on solid.
Low Battery = yellow light flashes slowly
Provided by www.ixium.co.uk

1. Power On/Off

2. Video/Photo Capture Button
3. Microphone
4. Camera Lens
5. Indicator Light
6. Mini USB charging Socket
7. Reset switch (recessed)
8. Micro SD card slot (SD Card NOT Included)
