Page 1: User Manual
DVI+Audio to HDMI Converter USER MANUAL Technical Support :... - Page 2 DVI+Audio to HDMI Converter Table of Contents 1.0 Introduction………………………………...…………...……..2 2.0 Specifications…………………………………….………..……3 3.0 Package Contents………………………………………….…..4 4.0 Panel Descriptions…………………………………….…….…4 5.0 Conection Diagram..............5 6.0 Troubleshooting……………………………………….…….…5 7.0 Limited Warranty……………………………………………..6...
- Page 3 Model No: Dear Customer Thanks for your purchase of the DVI Audio to HDMI Converter from CE-LINK. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
- Page 4 DVI+Audio to HDMI Converter 1.2 FEATURES The series of the Converter have many features that enable them to perform in a superior manner. Among those features you will find: l Supports HDCP l HDMI compliant l Toslink Audio and Digital Audio input/output l Supports HDTV resolutions l Easy to Use: Install in seconds, no need of setting.
- Page 5 DVI+Audio to HDMI Converter Regulatory Approvals Converter Unit FCC,CE,UL Power Supply UL,CE,FCC Accessories Adapter AC Power Adapter US standard, UK standard and so on User Manual English Version Note: Specifications are subject to change without notice. 3.0 PACKAGE CONTENTS Before attempting to use this unit, please check the packaging and make sure the following items are contained in the shipping carton: 1) Main unit (different models have different P/N).
- Page 6 HDCP encoding present. 6.1 Cable Length If you need to span a distance of greater than 3m to reach the converter, purchase CE-LINK’s Repeater which will allow you to extend a cable run up to 40m using premium cable. 7.0 LIMITED WARRANTY...
- Page 7 DVI+Audio to HDMI Converter that we will replace the defective product at no cost.Freight charges for the replacement unit will be paid by the customers. A copy of the invoice showing the item number and date of purchase (proof-of-purchase) must be submitted with the defective unit to constitute a valid in-warranty claim.
