Rycote Cyclone Small Quick Start Manual

Rycote Microphone Windshields Ltd
Libby's Drive, Slad Road, Stroud, Glos, GL5 1RN, U.K.
Email: tech_support@rycote.com
Web: rycote.com
Tel: +44 (0) 1453 759338
05/2017
1

Download Instructions

More information and full instructions can be downloaded here
https://rycote.zendesk.com/hc/en-us/articles/207948165-
Cyclone-User-Guide
2
Removing windshield
from the suspension
2 Use release tabs to separate the two
sections of the windshield
1 Undo safety catches
on both sides
3 Pull windshield away from
lower & upper suspension
3

Fitting microphone

Fit the mic into the
suspension
Fit the input
connector
to the mic
(XLR model
3
shown)
Support the mic
by evenly
positioning the
Lyres along
its length
The Lyres can be moved or replaced using
the hex key supplied.
4
Fitting windshield
to suspension
1 Ensure safety catches
are in the open position
on both sides
2 Fit both sides of the windshield to the
upper & lower basket suspension pods
3 Rotate the four safety catches into closed position
5
Removing and
refitting the C-Arm
Whilst pulling the C-Arm, press down the
release tab and the C-Arm will pull out
Release tab
Re-fitting is the reverse, and
ensure to push the C-Arm in
firmly until fully home
If the suspension is needed in a restricted
space, like a ceiling shot, the suspension
can be used without the C-Arm fitted.
Advanced Windshield System
Quick Start Guide
Cyclone Small
