Summary of Contents for Haas Door 610
- Page 1 COMMERCIAL 600 SERIES OPERATION & MAINTENANCE MANUAL COMMERCIAL SERIES...
- Page 4 Max. Door Size Section Skins Door End Stile Model Thickness R-Value* Width Height Type Inside Outside 1-3/8” Extruded 26 GA V-Groove 26 GA Flush 13.45 18’-2” 16’-0” (34.9mm) End Cap Woodgrain Steel Woodgrain Steel 1-3/8” Extruded 26 GA V-Groove 26 GA V-Groove 13.45 18’-2”...
- Page 6 Haas Door Commercial Instruction Manual Commercial Installation Manual Supplimental Instructions Now Included: American Tradition Hardware & Painting Instructions CA & Full View Strut Installation 320 Sycamore Street Wauseon, OH 43567 Commercial Bearing Plate Installation Cylinder Lock Assembly www.haasdoor.com KCLA Drilling Templates...
- Page 7 Haas Door Commercial Instruction Manual OPENING PREPARATION Note : All framing materials must be provided by building contractor or installer. Some large doors may require additional pad or pads located off All vertical jambs center to accommodate and pads regardless Figure 2 auxiliary bearings.
- Page 8 Haas Door Commercial Instruction Manual INSTALLATION OF VERTICAL TRACKS STEP 3 Position bottom section in center of the opening, allowing equal distance from each side of the opening. STEP 4 Position left hand track over rollers as shown in Figure 4. Space track 1/2” from door as shown.
- Page 9 Haas Door Commercial Instruction Manual HINGE SCHEDULE STEP 6 Complete the remainder of the sections at this time. Top door section should only be installed after horizontal track or full vertical track has been installed. Note: if door is supplied with full view aluminum section(s), attach hinges with 1/4”...
- Page 10 Haas Door Commercial Instruction Manual STEP 9b VERTICAL LIFT TRACK STEP 9a HI-LIFT TRACK Place upper vertical track on top of lower vertical track. Connect vertical hi-lift track to top of existing vertical track Plumb track and attach to wall in same manner as lower with 1/4”x 5/8”...
- Page 11 Haas Door Commercial Instruction Manual WARNING: Installing torsion springs can be a dangerous procedure and should only be performed by qualified door service personnel. Do not attempt installation without proper tools and until reading and understanding the following instructions. STEP 12 COUNTERBALANCE INSTALLATION Determine what type of spring assembly you have as shown in figures 12, 13, 14 or 15.
- Page 12 Haas Door Commercial Instruction Manual STEP 14 Raise the shaft assembly over the door. If 2 piece shaft with coupling is supplied, raise half the total shaft at a time. Rest the end(s) of shaft on the horizontal track angle.
- Page 13 (This may be required more frequently for high usage doors.) Haas Door recommends servicing any part of the counterbalance system including springs, drums cables, bearing brackets, and bottom corner brackets where cable is attached be performed by qualified door service personnel only (see notice below).
- Page 14 (1) year from date of installation. This ten year Warranty applies only to steel garage door sections manufactured by Haas Door Company and components manufactured or supplied by Haas Door Company. The warranty excludes: (1) Sections and/or component parts which have been damaged due to misuse;...
