Installation
•
Please use Cat5e or Cat6 TP cables not exceeding 100m in length to
connect to network PD devices
•
Connect power adapter to mains and to back power jack
•
Power the RB-GES401-POE switch and check LED status for proper
operation
PoE
PWR
5- Port Ethernet Switch with 4 PoE
Gigabit Ethernet PoE Port
Troubleshooting
•
Make sure all cables are following the EIA/TIA568A or 568B
specifications
•
If one end is following EIA/TIA 568A or 568B, the other end of
same cable must be same identical type
•
Check PD devices for power consumption, no single port should
exceed 30W load
•
Check that all PoE PD devices do not exceed 60W total consumption
RB-GES401-POE
Gigabit Ethernet Switch
Uplink
Up-link Ethernet Port
4
Gigabit PoE Ethernet
Switch
RB-GES401-POE
www.robofiber.com
User Manual
Advertisement
Summary of Contents for ROBOfiber RB-GES401-POE
-
Page 1: User Manual
PD devices Switch • Connect power adapter to mains and to back power jack • Power the RB-GES401-POE switch and check LED status for proper operation RB-GES401-POE Uplink 5- Port Ethernet Switch with 4 PoE Gigabit Ethernet PoE Port... - Page 2 IEEE 802.3/802.3u/802.3ab/802.3af/802.3at PoE Output Pin Assignment and Polarity: 1/2 (+), 3/6 (-), Output The RB-GES401-POE is a simple but reliable Gigabit Ethernet switch. Switch has a total Power: up to 30W/port, orange LEDs, not exceeding PoE output of 60 watts.
