Specification
CJ-3412C
Model
Pick up Element
1/3" SONY Super HAD CCD II
Effective Picture Elements
NTSC:768(H)×494(V)
(H×V)
Horizontal Resolution
650 TV Line
Minimum Illumination
0.001 Lux/F1.2
S/N Ratio
More than 52dB
2:1 interface
Scanning System
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
NTSC: 1/60s~1/100,000s
0.45
Gama Characteristic
Video Output
1Vpp, 75Ω
Auto Gain Control
Auto
DC12V(+/-10%)/150mA
Power/Current
3.7mm Taper Pinhole
Lens
.98(W) x.40(H) x.98(D)
Dimension (in)
.27
Weight (lb)
Storage Temperature
-22°~140°F RH95% MAX
Operating Temperature
14°~122°F RH95% MAX
Packing List
No
Name
Model
1.
Miniature Color Camera
CJ-3412C
2.
User Guide
CJ-3412C
Number
GREENSBORO, NC
1
1
ALLIANCE DRIVE
-
-CREST/
-
-
FAX:
-
-
www.crestelectro ics.co
CJ-3412C Color Camera
Miniature Color Camera
NOTE:
Please read this guide
BEFORE installing
Advertisement
Summary of Contents for Crest Audio CJ-3412C
-
Page 1: Packing List
Specification CJ-3412C Model CJ-3412C Color Camera Pick up Element 1/3" SONY Super HAD CCD II Effective Picture Elements NTSC:768(H)×494(V) (H×V) Horizontal Resolution 650 TV Line Minimum Illumination 0.001 Lux/F1.2 S/N Ratio More than 52dB 2:1 interface Scanning System Miniature Color Camera Synchronous System Internal, Negative sync. -
Page 2: Troubleshooting
INTRODUCTION BRIEF OF PRODUCT CONNECTING The Crest Electronics CJ-3412C camera is based on the * Sensor (CCD) latest high-resolution 960H sensor and is capable of deliv- ering a resolution of 650TVL. The Wide Dynamic Range SONY 1/3" CCD Sensor. of the sensor allows the camera to capture detailed imag-...
