ECHOMAX Active-X-Band Operation Manual

Echo X-XS Manuals A5 2013 final:Echo X/XS Manuals
MOUNTING


14˚


RADAR
14˚

28˚
RTE Mast top – horizon (not response) +/- 25 miles
Pushpit – horizon (not response) +/- 4–6 miles.
Lower installations may require trial and error to find the
best location and may be subject to slight shadowing.
OPTIONAL EXTRAS
We expect to have a new slimline – flushmount waterproof
control box available August 2013
Base fitting: female 1 inch – 14 NF thread
Mast Bracket: 26cm reach and female 1 inch – 14 NF thread
60cm Stainless Steel Extension Pole: 1 inch 14 NF thread to
take the RTE above the vessels radar.
Flush Mount Kit for Control Box: Length 111mm Height 70mm
Specifications given in this manual are subject to change
without notification.
A5 2011L 16/5/13
Declaration of Conformity
(As required by Article 6.3 of Directive 1999/5/EC-RTTE
Directive)
Declares under his sole responsibility that the active
radar target enhancer manufactured by:

AQUAMATE PRODUCTS LTD. also trading as
ECHOMAX
 PO Box 6032
Dunmow
Essex CM6 3AS U.K.

Telephone + 00 44 (0) 1371 830216 Fax 831733
Email: echomaxsales@aol.com
Intended for Worldwide use as an X Band active radar
target enhancer aboard non SOLAS vessels and identified
by the type number Active-X to which this declaration
refers has been tested to the essential radio, EMC &
safety test suites required by the notified body and is
in conformity with the standards.
EN60945: 2002 (Clauses 9, 10 & 12)
And complies with the essential requirements of
Directive 1999/5/EC. CE 0191: Performance
requirements of ISO 8729-2 X Band Radar.
Conformity procedure under Annex IV of 1999/5/EC
(Technical Construction File) has been undertaken by
QinetiQ (0191) of Cody Technology Park, Ively Road,
Farnborough GU14 0LX UK.
The Technical Construction File is held by:-
John H Simpson
AQUAMATE PRODUCTS LTD. also trading as ECHOMAX
PO Box 6032
Dunmow
Essex CM6 3AS U.K.
Tel: 00 44 (0)1371 830216 Fax 831733
Email: echomaxsales@aol.com
Signed .............................................
John H. Simpson Managing Director September 2009
GUARANTEE
The Echomax Active-X-Band RTE is guaranteed for 12
months from the date of purchase and provides for the
replacement at our discretion of the complete unit or
any of the components providing failure is attributed to
component failure or defect which is not attributed to
accidents, misuse, fair wear or tear or neglect.
The guarantee is invalidated by any attempt whatsoever
to open up or interfere in any way with the unit.
It is the users responsibility to return the unit at his
expense to us to inspect and report on the reason
for failure. No exchange unit will be given until a full
inspection and report is issued.
This guarantee does
not affect your statutory
consumer rights or AT BE BG CY CZ DK
those governed by
EE FI FR DE GR HU
local Law.
IS IE IT LV LT LU
For comparison with
competing products
MT NL NO PL RO SK
see:
SI ES SE CH LI GB
www.echomax.co.uk.
09:33 Page 1
...a significant advance in marine safety!
Active-X-Band
TURKISH PERMISSION REP: B.62.0.BTK.0.11.244.02/17595/8059
EMAXM UK 0513
Active-X-Band
Radar Target Enhancer
Radar Target Enhancer
OPERATION MANUAL
Echomax Active-X-Band RTE shown with optional base fitting
FCC CERTIFICATION ID: XZMACTIVE-X
0191
Manufactured by
Echomax Products in the UK
PO Box 6032, Dunmow CM6 3AS, UK.
Email: echomaxsales@aol.com www.echomax.co.uk
Tel: 00 44 (0) 1371 830216 Fax: 831733
