Valencia Corner Arbour (Assembly) 13/12/12
STEP 4
Create roof support / rear corner
post.
Fix 1x Roof Beam (R) to the front
right hand side assembly ensuring
flush with post (B). Follow around the
structure until square (note: post
joints are offset as Fig.4), using 18x
(x) fixing Back Corner Post (A) with
right angle cut facing front.
Fix Front Support Beam (M) using 4x
(x) and then Corner Support Beam
(N) using 4x (x). Finally, add the
Support Strut (P) to the front using
another 4x (x) as in Fig.4.
Note: the roof support strut can now
be added, (measuring the centre
between corner to corner), using 4x
(z). However, do not tighten just yet.
STEP 5
Fix back panels, table and corner
supports.
Fix the Table Top (G) using 4x (x)
ensuring square and level. Fix the four
Large Back Trellis Panels (J) using 6x
(x) for each panel as Fig.5.
Note: keep the panels front edge at
the front of the structure. Fix the two
Corner Supports (K) using 4x (y) in
each support as Fig.9.
STEP 6
Roof sections.
Fix the Roof Sections (L) together in
pairs making 4 equal roof sections
using 2x (z) in each pair. Position the
roof sections on the roof, resting on
Roof Vertical Support (Q) and
levelling off around the roof (it is
recommended to tie roof sections
together at this time using some
string).
Once all of the sections are level, fix
the roof using screws (x) x16. Untie
the roof sections and check all fixings
are tight and secure.
The structure is now complete.
