Energenie ENER101 User Manual

Features
USB output charger port
Solar or miniUSB input charging port
Fixed voltage constant current charging
LED Torch: normal, bright, ashing, SOS
LED status display: charging, discharging, battery
level, low battery.
1
3
2
4 5 6
1. Solar panel
F 100% Full
2. Smart button
75%
3. Status lights
50%
4. MiniUSB port (in)
L
25%
5. USB port (out)
Solar charging
6. LED torch light
Charging
Out of the Box
Before the charger is used for the rst time, it
must be charged via a computer USB port or
similar for at least 2 hours.
Instant Battery Power Check
Press the Smart button on the side brie y and the level
of the internal battery of the charger will be dispayed
on the status LED lights. During the output charging,
press push button P/C to check battery power available
in the unit. This will be indicated by the 4 status lamps
which will illuminate for several seconds
Charging your mobile device
1. Connect your mobile device to the charger via the
USB cable and the correct connector for your device.
2. Initiate charging with a 2 second press of the Smart
button on the side of the unit. The red charging light
will illuminate indicating charging in progress.
3. When the mobile device is fully charged, charging
will terminate automatically and the red light will extin-
guish.
4. Charging can also be manually terminated at any
time by pressing the Smart button for 2 seconds.
Phone Charger
USB
Note 1: If the Smart button is pressed as above and no mobile
device is attached or the device is fully charged, the charger will
detect this and switch o charging after 30 seconds.
Note 2: If the charger battery level becomes low, the green LED
will ash continuously for 5 minutes and the charging process
will then terminate.
Note 3: In-built over-discharge protection prevents damage to
the internal battery of the charger
Charging via sunshine and USB
The internal Lithium ion battery is charged either from
the sun or via its mini USB port.
a. Place directly under strong sunlight. A green light
indicates solar charging.
b. Connect the charger using the USB cable supplied
via the MiniUSB port of the charger to a laptop, PC, car
charger or other USB source. Charging will start auto-
matically.
Instant battery level will be shown on the four status
lights. When all four lights stay on without ashing, the
battery is fully charged.
During charging of the charger itself, the button is
inhibited from use.
Note: Over-charge protection prevents damage to the internal
battery.
AC adaptor
Car charger
Torch
1. The LED torch is operated by pressing the smart
button for longer than 2 seconds.
2. The display will cycle through 4 display modes
with each successive short button press:
normal -> bright -> ashing -> SOS
3. Holding the button down will turn the torch o .
