- Page 1 I303S Bluetooth ® Headset & Intercom for Scooters and Motorcycles User's Guide givimoto.com...
-
Page 2: Table Of Contents
Enabling/Disabling Voice Activated Phone Answering ......18 2. PACKAGE CONTENTS ................4 Enabling/Disabling Voice Prompts ............. 18 Installing the I303S on Your Helmet - Attachable Boom Microphone Type .. 5 Delete All Bluetooth Pairing Information ............. 18 3. GETTING STARTED ................5 Reset to Factory Default Setting .............. -
Page 3: Introduction
Thank you for choosing the GIVI I303S, Bluetooth Headset and Intercom • Bluetooth stereo headset for Bluetooth GPS navigations for Scooters and Motorcycles. With the I303S, you can call handsfree on • Bluetooth intercom up to 200 meters (220 yards)* your Bluetooth mobile phone, listen to stereo music or GPS navigation •... -
Page 4: Package Contents
I303S 2. PACKAGE CONTENTS Status LED Pin-hole Reset Button Attachable Boom Microphone USB Power & Data Cable (+) Button (Phone, Music) Speakers Hook and Loop Fasteners Hook and Loop Fastener for Speakers for Microphone Microphone (–) Button connector (Intercom) Microphone Sponges Double Sided Adhesive Tape DC Power Charging &... -
Page 5: Installing The I303S On Your Helmet - Attachable Boom Microphone Type
I303S 3. GETTING STARTED Installing the I303S on Your Helmet - Attachable Boom Microphone Type 1. Peel off the hook fasteners for the speakers and attach them on the back sides of the speakers. 2. Attach the loop fasteners for the speakers in the deep ear pockets of your helmet. -
Page 6: Powering On
I303S Powering On Press and hold the (+) Button and the (–) Button at the same time for 1 second to power on. The blue LED turns on and you will hear ascending beeps and “Hello”. Powering Off Press the (+) Button and the (–) Button at the same time. The red LED turns on for about 2 seconds until it turns off completely and you will hear “Goodbye”... -
Page 7: Charging The I303S
I303S Charging the I303S Note: You can charge the I303S by connecting the supplied USB power & data 1. The USB power & data cable is also used for firmware upgrade of the I303S. cable into a computer USB port or USB wall charger. You can use any 2. The USB wall charger is not included in the package. Any 3rd party USB standard micro-USB cable to charge the I303S. -
Page 8: Adjusting The Volume Level
Fault Reset “Low battery”. When the I303S is not working properly or is in faulty status for any Adjusting the Volume Level reason, you may reset by pushing the pin-hole reset button on the left You can easily adjust the volume by pressing the (+) Button or the speaker unit. -
Page 9: Operation Quick Reference
4. OPERATION QUICK REFERENCE 5 sec. I303S v1.0 Function Operations 1 sec. 1 sec. 1 press 1 press Bluetooth Power Select GIVI I303S On/Off Pairing (Phone, MP3, Power On Power Off GPS) 1 press 1 press I303S v1.0 Volume I303S v1.0... - Page 10 I303S Operations Operations Function Function 1 press 1 sec. Answer 2 sec. 2 sec. Music 3 sec. 2 sec. Mobile Phone Voice Dial 3 sec. * You can use “Voice Dial” and “Redial” only in stand-by mode. 2 sec. Reject...
-
Page 11: Mobile Phone Pairing
2. To pair the second mobile phone, press and hold the (–) Button for 1 Turn on the I303S and press and hold the (+) Button for 5 seconds 5 seconds until the red LED is rapidly flashing and you hear multiple until the LED flashes red and blue alternately and you hear multiple beeps. -
Page 12: Bluetooth Stereo Device Pairing
1. If the Bluetooth stereo device is integrated with the mobile phone such as smartphones, you don’t need to pair the I303S with it separately. When the I303S is paired with the mobile phone, it is also paired as a stereo music device. - Page 13 Pairing Pairing 3. Search for Bluetooth devices on the GPS navigation screen. Select the GIVI I303S in the list of the devices detected on the GPS. A2DP 4. Enter 0000 for the PIN. 5. The GPS confirms that pairing has completed and the I303S is ready to use.
- Page 14 Bluetooth stereo music source, you can pair the GPS to the I303S by following the simple procedures in “Mobile Phone Pairing”. When you do this, the I303S thinks the GPS is a mobile phone. But the I303S can directly pair an additional mobile phone.
-
Page 15: Mobile Phone Call Making And Answering
You can listen to stereo music by Bluetooth wireless stereo. The Bluetooth 4. To reject a call, press and hold the (–) Button for 2 seconds until you audio device must be paired with the I303S by following the “Bluetooth hear a beep while the phone is ringing. -
Page 16: Intercom Conversation
1. When you have an incoming mobile phone call during an intercom 1. Turn on the two I303S headsets (A and B) that you would like to pair conversation, you will hear a ring tone. You can choose whether to 1) with each other. -
Page 17: Intercom Failure
(–) Button. If your intercom friend goes out of range while having an intercom 4. If any button is not pressed within 10 seconds, the I303S will exit the conversation, you may hear static noise and eventually the intercom will configuration and goes back to standby. -
Page 18: Enabling/Disabling Voice Activated Phone Answering
VOX feature does not work if you are connected to intercom. To delete all Bluetooth pairing information of the I303S, press the (+) This is enabled from the factory but you can disable this. If this mode is Button until you hear a voice prompt, “Delete all pairings”, and press... -
Page 19: Reset To Factory Default Setting
“Delete all pairings” Execute Execute “Factory reset” To restore factory default settings on the I303S, press the (+) Button until you hear a voice prompt, “Factory reset”. Press the (–) Button to confirm. “Exit configuration” Execute The I303S powers off with a voice prompt, “Headset reset, goodbye”. -
Page 20: Firmware Upgrade
CERTIFICATION AND SAFETY APPROVALS 8. FIRMWARE UPGRADE FCC Compliance Statement The I303S supports firmware upgrade function. Please visit GIVI web This device complies with part 15 of the FCC rules. Operation is subject site at www.givimoto.com to check the latest software downloads. -
Page 21: Fcc Rf Exposure Statement
Bluetooth SIG, Inc. FCC Caution and any use of such marks by GIVI is under license. Other trademarks and trade names are those of their respective owners. Any changes or modifications to the equipment not expressly approved ®... -
Page 22: Weee (Waste Electrical And Electronic Equipment )
I303S WEEE (Waste Electrical and Electronic Equipment ) SAFETY INFORMATION The crossed-out wheel bin symbol on the product, Please ensure that the product is properly used by observing the literature, or packaging reminds you that all electrical and warnings and cautions below to prevent any risk and/or damage to electronic products, batteries, and accumulators must be property. -
Page 23: Product Use
I303S • Do not use the product near hazardous explosives. When it is near • Do not store the product in humid environments, especially for long any explosion hazards, turn off the power and heed any time storage. regulations, instructions, and signs in the area. -
Page 24: Battery
• Any 3rd party USB charger can be used with GIVI products if the charger is approved by either the FCC, CE, IC or other locally approved agencies that GIVI accepts. -
Page 25: Product Warranty And Disclaimer
Use of this product will constitute consent to warranty. Here, product warranty extends to the product only. GIVI will this agreement, and forfeiture of rights to all claims. If you do not consent... - Page 26 Therefore, you must take full responsibility for any of GIVI (collectively referred to as “the company”) recommend damage or loss caused by all risk factors which may occur when that, before using the product and similar devices of any brands using the product.
-
Page 27: Warranty Exclusions
LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, have occurred while you use the product. Further, GIVI will not be liable INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR... -
Page 28: Warranty Service
In addition to damages which may occur due to the use of the product, To obtain product warranty service, send the defective product, at your GIVI will not be liable for damages of the product which occur due to the expense, to the manufacturer or the seller along with proof of purchase (a following events. - Page 29 I303S...
- Page 30 1.1.3 givimoto.com User's Guide for Firmware v1.2...
