Ascent Solar XD 48 User Manual

Please review the following information before using your Ascent XD

INCLUDED

Ascent XD48 Solar Charger

HOW IT WORKS

The Ascent XD48 is designed for outside use to charge high-capacity power banks and other
compatible devices.
1. Unfold: Completely unfold the Ascent XD48 Solar Charger to ensure all twelve panels are solar-side
up and exposed to the sun.
2. Connect to Panel: Locate the two-pin connection end of the 2 meter Micro-Con-X
Dell connector cable. Plug the two-pin connection end into the solar output port on the solar
charger. Turn locking nut clockwise until it clicks firmly into place.
3. Connect to Device: Locate the barrel connection end on the opposite end of the connector cable.
Plug the barrel connection end into the solar input port on your device.
For device charge times, please visit www.AscentSolar.com.

FOR BEST CHARGING PERFORMANCE

Ensure that the panel is angled towards the sun to receive the most direct sunlight.
Average Performance

FOLDING THE ASCENT XD48

Always ensure the panels are folded solar-side in.

USER GUIDE

MODEL 800360
Solar
Output Port
4 x Carabiners
Collect
48 Solar Charger.
TM
4 x Elastic Bands
Store
Best Performance
2 meter Micro-Con-X
to 7.4 x 5.0mm Dell
connector cable
to 7.4 x 5.0mm
®
Power
®
