HT807 HUNTER Ins (a)
2/20/07
12:11 PM
Caution – Important Safeguards
When using an electrical appliance, basic precautions should always be observed, including the
following:
To reduce the risk of fire, electric shock, or injury read all safeguards and instructions
carefully before using this product and retain for future reference.
•
Do not leave the appliance connected to an electrical outlet when it is not in use.
•
Do not operate this appliance if the cord or plug has been damaged or after the
appliance has malfunctioned in any manner.
•
Never disconnect the cord by pulling it from the outlet; grasp the plug and pull to
disconnect.
•
Do not pull or carry by the cord, use the cord as a handle, close a door on the cord or
pull the cord around sharp corners or edges.
•
Do not allow the cord to make contact with hot surfaces.
•
Do not use extension cords or outlets with inadequate current rating. Care should be
taken to arrange the cord so that it can not be pulled or tripped over.
•
Do not run any of the attachments over the cord or allow the cord to come into contact
with the roller brush.
•
Do not handle the plug or vacuum cleaner with wet hands.
•
Use only as described in this manual and use only the manufacturer's recommended
attachments and accessories.
•
Do not treat it as a toy. Close attention is necessary when used near children, pets
or plants.
•
Do not use outdoors or on wet surfaces.
•
Do not put any objects into the openings, or use with any opening blocked.
Keep all openings free of dust, lint, hair, and anything which may restrict the airflow.
•
Keep hair, loose clothing, fingers and all parts of the body away from the openings and
moving parts.
•
Do not pick up hot coals, cigarette butts, matches or any hot, smoking, or burning
objects.
•
Avoid picking up hard or sharp objects such as glass, nails, screws, coins, etc.
•
Do not pick up flammable, toxic or combustible materials, or use in areas where they
may be present.
•
Take extra care when vacuuming on stairs and keep your work area well lit.
•
Unplug the appliance from the electrical outlet before adding or removing components
or cleaning.
•
Turn off all controls before unplugging the cleaner from the mains outlet.
•
Store your vacuum cleaner indoors in a cool, dry area.
•
This unit is for household use only.
SAVE THESE INSTRUCTIONS
Ensure the above safety precautions are understood
Page 1
2
Trouble Shooting Guide
PROBLEM
POSSIBLE REASON
Hand Vacuum
1. Power cord not firmly plugged
Cleaner will not
into outlet.
operate.
2. No power in wall outlet.
Hand Vacuum
1. Dust cup is full.
Cleaner will not
2. Hose (5) clogged.
pick-up or suction
3. HEPA Filter needs cleaning or
power is weak.
replacing.
4. Belt stretched or broken.
1. Dust cup is full.
Dust escaping from
2. HEPA Filter is not installed
Hand Vacuum
correctly.
Cleaner.
3. There is a puncture/hole in
HEPA Filter.
Hand Vacuum
1. Hose clogged.
Cleaner hose or
2. Dust cup is full.
attachments will
not pick-up.
Guarantee and Service Information
Home-tek electrical appliances are fully guaranteed for one year from the
date of original purchase against any deficiency or fault in manufacture.
This guarantee in no way prejudices your rights under common law and is
offered as an addition to consumers' statutory rights.
This guarantee does not cover normal wear and tear, damage caused by
overloading, negligence, accident or improper use. Any change or
modification made by the purchaser or user to the appliance will invalidate
the guarantee, as would any attempted repair.
The guarantee applies only when the appliance has been operated in
accordance with the instructions and connected to an electricity supply,
which matches that shown on the base of the appliance.
The guarantee will be rendered invalid if the product is resold. The product
must be used solely for domestic purposes.
POSSIBLE SOLUTION
1. Plug unit in firmly
2. Checkfuse or breaker.
Replace fuse/reset breaker.
1. Empty dust cup (see page 5).
2. Turn unit off and unplug from
wall outlet. Remove HEPA Filter
and check for objects in air duct
and remove.
3. Clean or replace HEPA Filter.
(see page 5)
4. Replace belt. (see page 6)
1. Empty dust cup.
2. Review HEPA Filter instructions.
(see page 5)
3. Replace HEPA Filter. (see page 5)
1. Remove hose and/or bushes.
Remove obstruction from hose.
2. Empty and clean dust cup.
7
Advertisement
Table of Contents
Summary of Contents for Home-tek HT807
-
Page 1: Trouble Shooting Guide
Do not pick up flammable, toxic or combustible materials, or use in areas where they may be present. Home-tek electrical appliances are fully guaranteed for one year from the • Take extra care when vacuuming on stairs and keep your work area well lit. -
Page 2: Operating Instructions
HT807 HUNTER Ins (a) 2/20/07 12:12 PM Page 3 Operating Instructions Cleaning and Maintenance NOTE: The HEPA Filter must be used when operating the hand vacuum. Cleaning & Changing the HEPA Filter WARNING: Always unplug the unit from electrical outlet before opening the dust cup container. -
Page 3: Main Components
HT807 HUNTER Ins (a) 2/20/07 12:12 PM Page 5 • Vigorously tap the HEPA Filter on a hard surface IMPORTANT Electrical Requirements: until no more dust is observed falling out from Please ensure that the voltage shown on the rating plate of your appliance corresponds with your between the pleats of the filter, a soft brush can household electricity supply which must be A.C. - Page 4 HT807 HUNTER Ins (a) 2/20/07 12:12 PM Page 7 After Sales Service Returns Form - Guarantee Slip If your appliance requires attention: Hunter Hand-held Turbo Vacuum Cleaner 1. Firstly check the operating instructions supplied to make sure the failure is not due to a problem you can rectify yourself.
Need help?
Do you have a question about the HT807 and is the answer not in the manual?
Questions and answers
How to replace drive belt
To replace the drive belt on a Home-tek HT807 handheld vacuum cleaner, follow these steps:
1. Remove the Brush Safety Cover – Hinge it forward and spring it off the edge using slight sideways pressure.
2. Remove the Casing Screw – It is adjacent to the silver shield cover. Once removed, slide the shield down 3-4mm and lift it away.
3. Remove the End Cover Screws – Two screws secure the end cover where the flexible hose fits. One screw goes through the wheel. Note the position and number of washers.
4. Lift Away the End Cover – This exposes the brush roller.
5. Remove the Brush Roller – Lift it out of the brush chamber. The brush bearing cap has a hexagonal end that should be noted for reassembly.
6. Clean the Brush and Bearing Caps – Remove any debris.
7. Install the New Belt – Thread it over the brush roller.
8. Reinsert the Brush Roller – Ensure the hexagonal end is positioned correctly in the brush chamber.
9. Replace the End Cover – Ensure it is properly aligned.
10. Reassemble the Vacuum – Secure all screws and covers.
This completes the belt replacement process.
