Zone A
Connect to SATA
Host with SATA
22-pin cable
Zone B
Connect to SATA
disk drive
Figure 2. The back view of the MX dongle board. The measured length is in mm.
Enova Technology Corporation Confidential
X-Wall MX Dongle board quick guide Rev 1.2
X-Wall MX Dongle Board Quick Guide
24C02B
SEEPROM that
contains AES key
Figure 1. The front view of the MX dongle board
Dimension: 68mm (L) X 28mm (W) X 18mm (H)
X-Wall MX Crypto Processor
Hardware AES 128, 192 or
256-bit Strength.
Zone C
Extra Mini-USB Connector
Allows Enova mini-USB key fob
Page 1 of 2
Advertisement
Table of Contents
Summary of Contents for Enova X-Wall MX
- Page 1 Dimension: 68mm (L) X 28mm (W) X 18mm (H) Figure 2. The back view of the MX dongle board. The measured length is in mm. Enova Technology Corporation Confidential Page 1 of 2 X-Wall MX Dongle board quick guide Rev 1.2...
-
Page 2: Quick Installation
AES key, remove the key fob. 5. Power up your System. 6. Partition and Format this new X-Wall MX controlled disk drive with key fob ON and load OS and/or other applications software just like what you had performed with a regular unencrypted disk drive.
