Operation
Bluetooth Pairing
1
With the power on, the amplifier is ready to be paired.
2
Turn on the Bluetooth feature on your Bluetooth enabled device.
3
Select HIFI to pair.
Specifications
Output Power (Rated)
Total Harmonic Distortion
Minimum Speaker Impedance(ohm)
Signal-to-Noise Ratio(dB)
Frequency Response (±3dB)
Sensitivity(dB)
Power Supply
Bluetooth Version
Product Dimensions(mm)
Product Weight
Care And Maintenance
Do not use any abrasive, sourcing powder or solvent to clean the amplifier.
Clean it only with soft cloth slightly moistened with a mild detergent solution.
3
2x25W into 4ohm, 2x13W into 8ohm
＜0.4% /1W /Channel
4
103
20Hz - 20kHz
90
DC14.5V,4.5A
4.0 With APTx
250x180x55(9.8"x7.1"x2.2")
0.7kg
STEREO
BLUETOOTH MINI
AMPLIFIER
USER MANUAL
AMP-30BT
Advertisement
Table of Contents
Summary of Contents for Lumi audio AMP-30BT
-
Page 1: User Manual
Frequency Response (±3dB) 20Hz - 20kHz Sensitivity(dB) Power Supply DC14.5V,4.5A Bluetooth Version 4.0 With APTx AMP-30BT Product Dimensions(mm) 250x180x55(9.8"x7.1"x2.2") Product Weight 0.7kg Care And Maintenance Do not use any abrasive, sourcing powder or solvent to clean the amplifier. Clean it only with soft cloth slightly moistened with a mild detergent solution. - Page 2 Note: Prior to powering your amplifier on, please turn the volume control knob all the way to the Left. Powering your amplifier on at higher volume will damage your speakers. Rear Panel AMP-30BT Amplifier User Manual Speaker Output Antenna Port...
