GSN ACS-102 Installation Instructions

ACS-102
WIRELESS DUAL-CHANNEL
ALARM SYSTEM SET
INSTALLATION
INSTRUCTIONS AND
Technical SpecificationS
OC03
www.gsncompany.com
1
1. «PANIC BUTTON MODE».
This mode is used in security
systems. The alarm occurs by
pressing any of the remote control
buttons or by unauthorized receiver
opening.
«PANIC BUTTON MODE»
FEATURES:
A. POWER LOSS PROTECTION.
The relay operates in active mode.
In case of power loss or intentional
disconnection the relay opens its
contacts.
4
2. «SWITCHING MODE» (ON/OFF).
This mode is for use in control
systems of various devices.
Each pressing the remote control
button corresponds to one of the
relay positions (ON/OFF).
3. «HOLD MODE» (CONTINUOUS).
The receiver relay activates for the
period of continuous pressing any
of the remote control buttons.
4. «PULSE MODE» (PULSE).
The pressing one of the remote
control buttons causes the relay
to activate for 1 second.
7

INTRODUCTION.

ACS-102 is a wireless dual-channel
multi purpose alarm system
set designed for use as a
PANIC BUTTON IN SECURITY
SYSTEMS and for remote
controlling of:
• ELECTRICAL GATES
• SLIDING DOORS
• ELECTROMAGNETIC LOCKS
• AUTOMATIC BARRIERS
• ELECTRICAL CURTAINS
• LIGHTING APPLIANCES, ETC.
2
B. LAST EVENT MEMORY.
Press the remote control button -
receiver's LED starts blinking – the
memory timer is on. Timer's
operating period is 30 minutes.
After the period of 30 minutes the
memory is automatically erased.
NOTE!
The receiver memory saves only the
last event, erasing the previous one.
5
ACS-102 RECEIVER MEMORY
CAPACITY .
The receiver ACS-102 is capable of
memorizing up to 680 different codes
and thus of operating with 680 remote
controls.

THE REMOTE CONTROL.

The wireless remote control has
two buttons corresponding to two
channels of the receiver.
Both buttons of the remote control
can be used to program and operate
the receiver.
8

ACS-102 RECEIVER FEATURES.

- Two independent channels
- Four operating modes for each
channel:
1. PANIC BUTTON MODE
(SECURITY)

2. SWITCHING MODE (ON/OFF)

3. HOLD MODE (CONTINUOUS)

4. PULSE MODE. 1 SECOND

- Maximum quantity of remote
controls programming the
receiver:.........................680(pcs)
- Easy receiver programming by
additional remote controls
- Unauthorized access protection
- Last event memory:.........30min
3
C. THE UNAUTHORIZED
OPENING PROTECTION.
In the «PANIC BUTTON MODE»
a tamper switch provides an
unauthorized opening protection
of the receiver.
ATTENTION!
In the «PANIC BUTTON MODE»
the receiver does not operate if the
cover is removed.
6

LED INDICATIONS.

1. LED is on – the receiver is
operating.
2. LED blinks – the memory timer is
on (in the Panic Button Mode).

OPERATING MODE SELECTION.

1. Disconnect power.
2. Remove the cover.
3. Place jumpers at the desired
setting (see Figure 1).
4. Restore power.
5. Program the receiver by the
remote control.
6. Replace the cover.
9
