Summary of Contents for Rockford Fosgate Punch PSD-1
- Page 1 ® UNCH TATUS ISPLAY PSD-1 & O NSTALLATION PERATION ® ®...
-
Page 3: Practice Safe Sound
Congratulations on your purchase of the world's finest brand of car audio accessories. At Rockford Fosgate we are committed to musical reproduction at its best, and we are pleased you chose our product. Through years of engineering expertise, hand crafts- manship and critical testing procedures, we have created a wide range of products that reproduce music with all the clarity and richness you deserve. -
Page 4: Table Of Contents
Installation Section of this manual or refer to the icons listed below. Other information can be located by using the Table of Contents. We, at Rockford Fosgate, have worked very hard to make sure all the information in this manual is current. But, as we are constantly finding new ways to improve our product, this information is subject to change without notice. -
Page 5: Introduction
Rockford Fosgate stereo and mono amplifiers. We recommend you have your Authorized Rockford Fosgate Dealer install your new accessory. If you do choose to install the accessory yourself, please be sure to read the entire manual before beginning. -
Page 6: Design Features
6. Data Interface Jacks – The RJ45 interface provides a convenient connection for the data interface cable. 7. Remote/Dimmer Connector – The mini 2-pin connector provides a convenient connection for Remote Turn-On and Dimmer input. CLIP THERMAL THERMAL ® – 2 – CLIP SIGNAL ® POWER PSD-1... -
Page 7: Installation Considerations
Remote Disable Stereo/Mono Left Remote Enable 8. Remote Disable/Enable Jumper –The position of this jumper determines whether the PSD is turned on and off by the amplifier or with a separate switch. 9. Stereo/Mono Jumpers – These jumpers are used to configure the PSD for Stereo or Mono amplifier input(s). -
Page 8: Mounting Locations
OUNTING OCATIONS The Punch Status Display can be installed in a wide range of operating locations. However, care should be taken to ensure optimum monitoring without causing distractions under normal driving conditions. Listed below are the following options for installation. Engine Compartment Mounting the Punch Status Display in the engine compartment will void your warranty. -
Page 9: Wiring The System
I R I N G T H E For safety, disconnect the negative lead from the car battery prior to beginning the installation. 1. Route the Data Interface Cable inside the vehicle to provide the best protection. Leave slack at each end of the cable for the connection of the PSD and amplifier. -
Page 10: Installation
NSTALLATION Remote Turn-On/Dimmer Wiring Do Not Remote Jumper on PC Board Remote Disable • Remote Turn-On (Blue Wire) not used when Remote Jumper has been DISABLED (installed) • Dimmer (Orange Wire) will dim LEDs when connected to dimmer or “park light” lead (+12V when headlights are turned on) Remote Jumper on PC Board Remote... - Page 11 Remote Disable POWER SIGNAL CLIP • Stereo/Mono Jumpers are installed on jumper pins • 2-Channel Amp connects to Stereo/Mono Left input Stereo Amp THERMAL THERMAL ® ® – 7 – ® ® Remote Dimmer Stereo Amp CLIP SIGNAL POWER PSD-1...
- Page 12 Please contact Rockford Customer Service (800-669-9899) for information (if using 2 amps) Remote Dimmer Mono Amp(s) THERMAL THERMAL CLIP ® ® , Power 250m and Power 500m must – 8 – ® ® ® ® ® Mono Amp(s) SIGNAL POWER PSD-1...
- Page 13 Standard Mount Backstrap Screw & Washer (Screw 3/8" Max) • Install PSD into mounting bezel using the rear screw • Mount Backstrap securely to the PSD and the instrument panel • Backstrap Screw should be 3/8" max. (use supplied screw) ISO Mount Factory Bracket Adapter...
-
Page 14: System Diagrams
Y S T E M I A G R A M S Single Amp System POWER SIGNAL Full Range Monitor CLIP THERMAL THERMAL ® ® ® ® ® ® Tweeters Midrange Subwoofer – – 10 – CLIP SIGNAL POWER PSD-1... - Page 15 POWER SIGNAL Tweeter/Midrange Monitor CLIP THERMAL THERMAL ® ® Subwoofer Monitor CLIP THERMAL THERMAL ® ® ® ® ® ® Subwoofers ® ® ® ® – 11 – CLIP SIGNAL POWER PSD-1 CLIP SIGNAL POWER PSD-1 Tweeter Midrange Tweeter Midrange...
- Page 16 CLIP ® ® Subwoofer Monitor CLIP THERMAL THERMAL CLIP ® ® ® ® ® ® ® ® ® ® ® ® ® ® – 12 – SIGNAL POWER PSD-1 SIGNAL POWER PSD-1 SIGNAL POWER PSD-1 ® ® Subwoofers Midrange Tweeters...
- Page 17 ® ® Subwoofer Monitor THERMAL THERMAL CLIP ® ® ® ® ® ® ® ® ® ® ® ® ® ® – 13 – SIGNAL POWER PSD-1 SIGNAL POWER PSD-1 SIGNAL POWER PSD-1 ® ® Subwoofers Rear Stage Front Stage...
-
Page 18: Rockford Fosgate Accessories
OCKFORD PSD C (CC-1188) ABLES 20 foot 8-conductor cables are available separately for the connection of an additional mono amplifier to Punch Status Display. This will allow the PSD to accommodate a pair of Mono amplifiers operating individu- ally or a pair of Mono amplifiers bridged. R O U B L E S H O O T I N G Symptom PSD does not... - Page 19 Symptom PSD does not turn on (Thermal LED on) Random LEDs Illuminate Both POWER and/or THERMAL LEDs do not illuminate (Stereo Amp Con- nected) Both POWER and/ or THERMAL LEDs illuminate (Mono Amp Connected) LEDs do not dim (Headlights turned on) PSD shuts off when amp thermals (Remote Enabled)
-
Page 20: Specifications
Signal Clipping +90 C (+194 F) amplifier temperature or protection of power supply due to under/over voltage THERMAL CLIP SIGNAL ® ® 7" (17.8cm) 7-1/2" – 16 – POWER 3/4" (1.9cm) PSD-1 2-1/4" (5.7cm) 2-3/8" 2-1/16" (6cm) (5.2cm) 2-1/4" (5.7cm) -
Page 21: Warranty Information
Electronics found to be defective during the warranty period will be repaired or replaced at Rockford Fosgate’s discretion. Repaired or replaced electronics will be covered by the balance of the original warranty period only. Rockford Fosgate shall not be responsible for any incidental or consequential damages resulting from a defect in electronics. -
Page 22: International Information
– 18 –... - Page 23 ONECTANDO EL Por seguridad, desconecte el borne negativo de la bateria de su coche antes de comenzar la instalación. 1. Coloque el cable de Interficie de Datos en el interior de su vehiculo de manera que éste quede protegido. Deje un trozo libre y suelto en cada extremo del cable para poder conectar el PSD y el Amplificador.
- Page 24 NSTALACIÓN Conexionado del encendido remoto y del Dimmer No usar Jumper de remoto en la placa de PC Remote Disable • Encendido Remoto (cable Azul) no usado cuando el jumper del remoto ha sido desactivado • Dimmer (cable Naranja) oscurecerá los LEDs cuando sea conectado al cable de dimmer o de “luces de posición”...
- Page 25 • Los jumpers Stereo/Mono están colocados en los pines para jumpers • 2-Channel Amp se conecta a la entrada Stereo/Mono Left (Amplificador de 2 canales) Stereo Amp THERMAL THERMAL CLIP ® ® – 21 – ® Remote Dimmer Stereo Amp SIGNAL POWER PSD-1 ®...
- Page 26 Rockford para más información (800-669-9899) (Amplificador/es Mono) Remote Dimmer Mono Amp(s) THERMAL THERMAL CLIP ® ® , Power 500m y Power 250m deben usar el – 22 – (if using 2 amps) ® ® ® Mono Amp(s) SIGNAL POWER PSD-1 ® ®...
- Page 27 RANCHEMENT DU Pour votre sécurité, déconnectez la borne négative de la batterie avant de commencer l'installation. 1. Faire passer le cable d'interface dans le véhicule de manière à le protéger au maximum. Laisser du mou à chaque extrémité du cable afin de connecter le PSD et l'amplificateur.
- Page 28 NSTALLATION Commande d'allumage / Dimmer ne pas utiliser Pontage (“jumper”) Remote sur le circuit imprimé Remote Disable • La commande d'allumage (fil bleu) n'est pas utilisé lorsque le jumper est branché. • Le dimmer (fil orange) va assombrir les LEDs lorsqu'il est connecté à...
- Page 29 Disable POWER SIGNAL CLIP • Les pontages Stéréo/Mono sont placés • L'ampli stéréo se branche sur l'entrée de gauche (stereo/mono left) Stereo Amp THERMAL THERMAL CLIP ® ® – 25 – ® ® Remote Dimmer Stereo Amp SIGNAL POWER PSD-1...
- Page 30 NE PAS CONNECTER LE POWER 500 SUR LE PSD SANS L'ADAPTATEUR PRECONISE! (si deux amplis sont utilisés) Mono Amp(s) CLIP THERMAL THERMAL ® ® , Power 250m et Power 500m il faut – 26 – ® ® ® Remote Dimmer Mono Amp(s) CLIP SIGNAL POWER PSD-1 ® ®...
- Page 31 ERKABELUNG DES Zu Ihrer eigenen Sicherheit klemmen Sie bitte das Negativ-Kabel an Ihrer Batterie ab, bevor Sie mit dem Anschlie en beginnen 1. Ziehen Sie das Daten-Interface Kabel so durch Ihr Fahrzeug, da es den bestmöglichen Schutz hat. Achten Sie darauf das es nicht beschädigt werden kann.
- Page 32 INBAU Remote Einschalt-Kabel/Dimmer-Kabel Nicht benutzen Remote Jumper auf der Platine Remote Disable • Remote Einschalt Kabel nicht verwenden (blaues Kabel) wenn der Remote Jumper auf Disabled steht • Dimmer Kabel (Orange) reguliert die LEDs, wenn das Kabel mit der Instrumentenbeleuchtung Ihres Fahrzeuges verbunden wird (Oder Sie verwenden +12 Volt Kabel des Abblendlichtes.) entfernen Sie den Jumper von der Platine...
- Page 33 • Bei Stereo- oder Mono- Betrieb müssen die Jumper eingesetzt sein • Bei 2 Kanal Endstufen im Stereo/Mono Betrieb bitte den linken Eingang verwenden Stereo Amp THERMAL THERMAL CLIP ® ® – 29 – ® ® Remote Dimmer Stereo Amp SIGNAL POWER PSD-1...
- Page 34 04207-5046 Germany, 071-424647 Swiss und 0663- 839121 Austria. (if using 2 amps) Remote Dimmer Mono Amp(s) THERMAL THERMAL CLIP ® ® , Power 250m und Power 500m mu die – 30 – ® ® ® Mono Amp(s) SIGNAL POWER PSD-1 ® ®...
- Page 35 ABLARE IL Per motivi di sicurezza, disconnettere il cavo negativo dalla batteria prima di iniziare l'installazione. 1. Passare il cavo di interfaccia dati all'interno dell'auto con il percorso che permette la massima protezione. Lasciare un po’ di cavo in ecesso ad ogni estremitá...
- Page 36 NSTALLAZIONE Cablaggio del consenso ed illuminazione usare Ponticello di consenso sul circuito stampato Remote Disable • Cavo di consenso di accensione (blu) non impiegato quando il ponticello é inserito • Il cavo dell'illuminazione (arancione) abbassa la luminositá dei LED quando le luci dell'auto sono accese Ponticello di consenso sul circuito stampato Remote...
- Page 37 Disable POWER SIGNAL • I ponticelli Stereo/Mono sono installati sui pin • L'amplificatori 2 canali é connesso all'ingresso sinistro stereo/mono Stereo Amp CLIP THERMAL THERMAL ® ® – 33 – ® ® Remote Dimmer Stereo Amp CLIP SIGNAL POWER PSD-1...
- Page 38 Contattate il distributore Rockford Fosgate per ulteriori informazioni. (if using 2 amps) Remote Dimmer Mono Amp(s) THERMAL THERMAL CLIP ® ® , Power 250m and Power. – 34 – ® ® ® Mono Amp(s) SIGNAL POWER PSD-1 ® ®...
- Page 39 3/96 MAN-1208-A Rockford Fosgate Rockford Corporation 546 South Rockford Drive Tempe, Arizona 85281 U.S.A. In U.S.A., (602) 967-3565 In Europe, Fax (49) 4207-801250 In Japan, Fax (81) 559-79-1265...
