Summary of Contents for Syswin Solutions SmartAir Cube
- Page 1 SYSWIN SOLUTIONS SRL USER’S MANUAL SmartAir Cube “Sometimes all I need is THE AIR THAT I BREATHE And to love you”* Prepared by: Gaudentiu Varzaru Document ID: 515.09.002.00.02.57 Revision: Date: 23.05.2018 ---------------------------------------------- * The Hollies...
- Page 2 USER’S MANUAL SmartAir Cube SmartAir is a trade mark of Syswin Solutions. www.syswinsolutions.com...
-
Page 3: Table Of Contents
SUMMARY GENERAL WARNINGS 1.1. Purpose of this manual 1.2. To whom the manual is addressed 1.3. Responsibility 1.4. Manufacturer 1.5. Warranty 1.6. General safety warnings 2. DEVICE FEATURES 2.1. Interconnection diagram 2.2. Main features 2.3. Supply 2.4. Technical features 2.5. Terms of use 2.6. - Page 4 Caution: failure to follow the instructions contained in this manual may involve damages to the device. Should this manual be lost or damaged, you may request a copy from the manufacturer: please enclose the serial number of your device with your request.
-
Page 5: General Warnings
The manufacturer’s responsibility is confined to the correct use of the device, in the limits indicated in this manual. Syswin Solutions declines all responsibility for any damages caused to persons and/or to property as the result of: ● incorrect installation;... -
Page 6: Warranty
1.5. Warranty The warranty period of the SmartAir Cube device, starting from the date of the shown on the delivery note, is one year. The Warranty does not include damages to the device caused by: ● transport and/or handling; ● operators errors;... -
Page 7: Device Features
DEVICE FEATURES The SmartAir Cube device has been designed to detect indoor air quality based on the information provided by sensors specializing in the detection of gases (CO2, VOC), humidity and temperature. Information is transmitted via a wireless router to a remote server. The processed data is displayed on fixed (personal... -
Page 8: Supply
2.3. Supply The wireless detector device does not require an external power supply as it is equipped with a 3.7V, 2000mAh battery. The battery is recharged via a 5V mini USB port. 2.4. Technical specifications Feature Value Temperature measurement range -40°C ... -
Page 9: Installation
Terms of Use (section 2.5). The installation of the SmartAir Cube requires a source for powering, a WiFi router, and a device to connect to the air quality monitoring application. - Page 10 address: http://192.168.1.28 This is the device network configuration panel. Enter your home network credentials (SSID and password) and click Submit. The device is then going to connect to your network and use it to send data to the mobile/web application. Make sure you enter the correct information otherwise the connection will not be established.
-
Page 11: Data Acquisition
3.4. Data acquisition Step 1 : Step 2: Go to the following webpage: Register an account. - Page 12 Step 3: Step 4: Verify your e-mail. Log into your account and click the +Add sensor button from the drop- down menu.
- Page 13 Step 5: Step 6: Configure your sensor with the given ID. You can now see your sensor in the Sensor List menu. Repeat step 5 if you have multiple sensors.
-
Page 14: Maintenance
MAINTENANCE ● Handle with care the SmartAir Cube device to assure a longer useful life. ● Take care when handling e device, do not let it fall, knock it or move it suddenly. ● Use the appropriate USB connector. Do not force it when fitting as the connectors could be damaged. -
Page 15: Disposal And Recycling
DISPOSAL AND RECYCLING ● When SmartAir Cube device reaches the end of its useful life, it must be taken to an electronic equipment recycling point. ● The equipment must be disposed of in a selective waste collection system, and not that for urban solid residue. - Page 16 Added table for LED status description. 23/05/2018 Updated section 3.1. Preliminary information, 3.4. Data acquisition. Added picture for ON/OFF switch and Reset button. Updated table for LED status description. SYSWIN SOLUTIONS SRL 26 Biharia St, 3rd Floor, District 1 Bucharest, Romania 013981 www.syswinsolutions.com...
