DU-HA 70102 Installation Instructions

Replacement subwoofer box (with amp) for 09-10 ford f-150 supercab
Hide thumbs
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual
DU-HA Replacement Subwoofer Box (with amp)
for 09-10 Ford F-150 Supercab
1
STEP
Materials Needed:
8mm Socket
//
Phillips Screwdriver
//
Needlenose Pliers
//

To remove Factory Subwoofer:

Lift up rear passenger seat.
1
Remove 4 bolts pictured using an 8mm socket.
2
Turn subwoofer box over and unplug wires going into silver amp.
3
Remove 4 screws from amp box using a phillips screwdriver, then remove amp.
4
Remove 8 screws from the speaker using a phillips screwdriver as pictured.
5
Pull the speaker out of the box as far as possible. Apply light pressure up on the black
6
tab under the speaker, gently wiggle the metal plugs free from the speaker using a
needlenose pliers. Remove all 4 metal connectors from the speaker. Set speaker aside.
Pull cord that was originally plugged into the amp all the way out of the factory box.
7
"Step 2"
Go to
of installation instructions.
8
Part # 70102

Installation Instructions

Fits DU-HA Part Numbers
1
2
3
5
6
7
20096
20071
20072
20073

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 70102 and is the answer not in the manual?

Questions and answers

Summary of Contents for DU-HA 70102

  • Page 1: Installation Instructions

    Part # 70102 Installation Instructions DU-HA Replacement Subwoofer Box (with amp) Fits DU-HA Part Numbers for 09-10 Ford F-150 Supercab 20096 20071 20072 20073 STEP Materials Needed: 8mm Socket Phillips Screwdriver Needlenose Pliers To remove Factory Subwoofer: Lift up rear passenger seat.
  • Page 2 Feed speaker wire (the end with the smaller connectors) through the hole on the outside of DU-HA subwoofer box to the inside of box, leaving amp plug on the outside. Hook the connectors on the wires back to the speaker using a needlenose pliers.
  • Page 3 Part # 70102 Installation Instructions DU-HA Replacement Subwoofer Box (without amp) Fits DU-HA Part Numbers for 11-13 Ford F-150 Supercab 20096 20071 20072 20073 STEP Materials Needed: 8mm Socket Phillips Screwdriver Needlenose Pliers To remove Factory Subwoofer: Lift up rear passenger seat.
  • Page 4 Install finished DU-HA replacement subwoofer box inside DU-HA storage unit under back passenger seat of the truck. Pull Ford factory wire (on the floor on the passenger’s side) over the back of the DU-HA and plug the green ends together.
