KT-LCD3 e-Bike Display User Manual
Dear customer, please read this manual before you use KT-LCD3 instrument. The manual will guide
you use the instrument correctly to achieve a variety of vehicle control and vehicle status displays.
Functions and Display
Instruments using the structure form of instrument body portion and the operation buttons are
designed separately.
1 UP button
2 SW button
3 DOWN button
4 Battery capacity indicator
5 Backlight and headlights
6 The brake display
TM Single trip time
7
TTM Total trip time
MOTOR W Power display
MOTOR ℃
8 Motor temperature
MOTOR ℉
Motor Fahrenheit
℃
Environment temperature
9
℉
Environment Fahrenheit
Operation
1. ON/OFF
Hold button long to turn on the power, and hold
off the power. When the motor stops driving and when the e-bike is not used for a consecutive 5
minutes, it will automatically shut down and turn off the motor power supply.
2. Display 1
10 6KM/H push power assist
KM/H Riding speed(metric)
MPH Riding speed (imperial)
11
MXS MAX speed
AVS Average speed
Km Distance(metric)
Mil Distance (imperial)
12 DST Trip distance
ODO Total distance
VOL Battery voltage
ASSIST Pas level
13
CRUISE Cruise function
button long for a second time to turn
V3.0
2.1 Turn on backlight and headlights
controller should have headlight drive output function); hold
long again to turn off the backlight and headlights.
2.2 Assist ratio gear (ASSIST) switch
the minimum power, gear 5 is for the highest power. Each startup will
automatically restore the gear shutdown last time (the user can set
randomly). Gear 0 is without booster function.
2.3 6KM/H assist promotion function
more than 6Km /h. Release
2.4 Cruise function
than 7 km/ h, hold
or hold any button to cancel.
2.5 Display and delete of single data
same time, single trip riding time (TM) and single trip distance (DST) flash,
hold
the button within 5 seconds, it will automatically return the display interface after 5 seconds, original
content is preserved.
3. Display 2
In the riding mode after 5 seconds, display 2 automatically returns to display 1, and the original
motor power (MOTOR W) display is replaced with motor operating temperature display (MOTOR ℃)
Hold button to start up and enter display 1.
Hold button long to turn on backlight and headlights (the
Hold or button shortly to switch 1-5 file gear. Gear 1 is for
Hold button and flashes, the vehicle drives at the speed not
button, the function is invalid.
After the cruise function is turned on, the trip riding speed is greater
button long and enter cruise, the CRUISE lit. Brake
After power on for 5 seconds, hold
button shortly, the content of both is cleared. If failed holding
Hold button shortly in display 1 to enter display 2.
button
and button at the
