Dynamic Accents 52250 Instruction & Installation Manual

Thank You for choosing the Dynamic Accents Ltd. 36" Tall Pressure Mount Pet Gate for your pet containment
needs. Please keep this guide for future reference on installation of this product.
This product is proudly Made in the U.S.A. of solid White Oak and coated with non-toxic. water based finish.
This gate spans openings of 32" to 38" wide. For coverage of wider openings
up to 62" total, optional 6" and 12" extension kits are available for purchase.

Your Package Includes the following:

36" Tall Pressure Mount
Pet Gate with wall bumpers

Measure the opening to determine the width of coverage needed

and choose the appropriate parts needed based on the diagrams below
Openings
32" to 34" wide
Use Gate Only and adjust
wall bumpers for secure fit
36" Tall Pressure Mount Doorway Gate
Instruction/Installation Guide
2" Gate
Extensions
(x2)
Hex Key
Connector
Bolts (x4)
Openings
34" to 36" wide
Use Gate plus (1) 2"
Extension and adjust wall
bumpers for secure fit
Gate frame is intentionally wider
at the top because of the tension
design of the product. Bringing
the frame into alignment with the
gate door during installation
creates the tension effect to hold
the gate in place.
Gate door is affixed to frame with
spring hinges which apply
downward pressure to securely
latch the gate door to the bottom
frame. To open door, grasp top
rail, lift entire door slightly and
door will swing freely in either
direction
.
Openings
36" to 38" wide
Use Gate plus (2) 2"
Extensions and adjust wall
bumpers for secure fit
:
Is your opening more
than 38" wide?
STOP
You will need additional
extensions to cover
openings larger than 38"
wide. Improper
installation could result
in unexpected accident
or product damage.
