Absolon CIR-BA44GBC User Manual

Analog High Definition 4 IN 1 IR Camera
 ITEM №:
CIR-BA44GBC
 Caution for Installation
1. In order to prevent electronic shock, don't loosen any screws or covers.
2. Do not directly touch the front glass. If necessary, use a soft cloth
moistened with alcohol to wipe off the dust.
3. Avoid places where there are frequent vibrations or shocks.
4. Don't operate the camera beyond its temperature, power source
ratings.
5. When any abnormalities happen, make sure to unplug the camera and
contact your local dealer.
 Packing
1. Camera
2. User Manual
3. Screw
4 Plastic-Conical-Anchor
5. Hexagonal Wrench
6. Mounting drawing paper
X1
X1
X4
X4
X1
X1
 Specification
ITEM
IP Rating
Type
Signal System
Pick Up Device
Picture Elements
Min Illumination
S/N Ratio
Lens
3D/2D
SENS-UP
IR SMART
White Balance
Back Light Compensation
DWDR
OSD
Video Out-put
Power Supply
Current Consumption
IR Effect Distance
Dimension
Weight
Storage Temperature
Operating Temperature
Remark: Non-regulative adaptor may cause camera damaged.
CIR-BA44GBC
IP65
Removable IR Cut Filter
NTSC/PAL
1/2.7" 2.1 Mega Pixels CMOS
1920(H)X1080(V)
0Lux with IR LED 24 pieces
≥52dB
3.6mm Board Lens
ON
ON
ON
ATW
OFF
ON/OFF
YES
HD-AHD /HD-TVI/HD-CVI/ CVBS
DC12V ±10%
400mA（MAX）
15m (49.2ft) (Outdoor)
Φ94×80mm (3.7"×3.15" )
330g (11.64oz)
-30～+60℃ (-22～+140℉)
-30～+40℃ (-22～+104℉)
