SEAL Innovation SwimSafe SB User Manual

USER GUIDE
CONNECT
Plug in the SEAL SwimSafe ™ 4-Band Charger.
Place the SEAL SwimSafe ™ Band into the
4-Band Charger.
Rotate the swivel clamp over the Band
to hold it in place.
NOTE If the swivel clamp does not rotate
smoothly, be sure that the four metal
contact points on the face of the Band
are aligned with the pins in the Charger.
Place the SEAL SwimSafe ™ Hub into the
Charger. Indicator lights will appear.

PAIR

If your Band is flashing yellow,
it needs to be paired to the Hub.
To pair a Band with the Hub:
Remove the Band from the Charger,
then press the button on top of the Hub.
Rub the face of the Band
against the SEAL logo on the
side of the Hub. The Band and
Hub will flash while pairing.
When the Band and Hub
lights turn GREEN, the Band
is now synced with the Hub.
WHAT'S INCLUDED
SEAL SwimSafe™
Band (x1)
Adult Band
SEAL SwimSafe™
Extender (x1)
Hub (x1)
Interchangeable
Band Face Plates
(x3)
SET SWIM LEVELS
CHOOSING A SWIM LEVEL
The SEAL SwimSafe ™ System allows you
to set each Band to four different Swim
Levels. The user's swim ability and lung
capacity are important in determining
which Swim Level to choose.
NOTE Older adults or swimmers with
medical problems may need a lower
Swim Level to detect shorter periods
of submersion before alarming.
SEAL SwimSafe™
4-Band Charger (x1)
Power
Supply (x1)
CUSTOMER SUPPORT (888) 786-8721
customerservice@SEALSwimSafe.com
Visit www.SEALSwimSafe.com/userguide for
additional information and videos of product.

CHARGE

The SEAL SwimSafe ™ Band and Hub must
be charged in order to monitor swimmers.
Plug in the SEAL SwimSafe ™ Charger and
fully charge the Band and Hub before an
outing or a long day of swimming. Charge
the Band and Hub until the lights stay on
and are no longer flashing to indicate a
full charge.
CHARGING TIME (0% to full charge)
Band: 1.5 hours Hub: 3 to 4 hours
BATTERY LIFE
Up to 8 hours
The bands will blink RED until they have
reached the minimum usable charge.

SWIM LEVELS

Four different submersion time limits.
NON-SWIMMER BEGINNING & COMPETITION
Alarms seconds after RECREATIONAL ATHLETE
entering water. SWIMMER Up to 45 seconds
Up to 20 seconds submersion.
submerged.
GUARD LEVEL Allows the Band to act as another Hub,
alarming the wearer of any danger. Adults and lifeguards
are encouraged to wear the included Band extender and
orange faceplate with their Guard Band.
Swimmers should be set to level BLUE unless they can safely
and comfortably be under water for more than 20 seconds.
SEAL SwimSafe ™ alone can not protect
swimmers and can only be used in
conjunction with vigilant lifeguards or
parents/guardians and safe swimming
practices.
™
SEAL SwimSafe technology is for
in-ground pools and lakes only and will
not protect swimmers in above-ground
pools or hot tubs.
SEAL SwimSafe ™ alarms when a
swimmer is at least 12 inches underwater
and should not be used on swimmers
that are of an age or have disabilities
where they could drown in water shallow
enough to stand up in.

POWER UP

TURN ON THE SYSTEM by pressing the button on the top of the
Hub. The Hub light will flash RED, then GREEN. The Band will
flash the SWIM LEVEL COLOR (see "Swim Levels" section below),
and the Hub will begin flashing GREEN/WHITE
to indicate they are turned on and charging.
PRESS
NOTE Turn on a Band at any time by rubbing
the face of the Band against the SEAL logo on
the side of the Hub until you hear the Hub chirp,
or place the Band in the Charger connected to
a power source. The Band will begin flashing
the preset SWIM LEVEL COLOR.
TURN OFF THE SYSTEM by pressing and
holding the button on top of the Hub. The
Hub light will turn RED. This will turn off
the Hub and all Bands paired with the Hub.

CHANGING THE SWIM LEVEL

Select the appropriate Swim Level for each Band.
Secure the Band in the
Charger while plugged in.
Press the Swim
Level button.
Lights will flash
the Swim Level
color you select.
Remove the
Band and place
on swimmer.
