Interactive Technologies CueServer 2 Pro Quick Start Manual

Hardware Overview

40 Character x 2 Line LCD Display
Stereo Audio In/Out
USB Ports Reset Button
Power Input Dual LAN Ports
First Startup Procedure
1
Connect one end of Ethernet
cable to either of the LAN ports
on the back of the CueServer.
A B
Connect the other Or, connect the other end of the
end of the Ethernet Ethernet cable to Ethernet
cable to a DHCP switch or directly to an Ethernet
router. CueServer port of your computer. This
will automatically requires the IP addresses of
obtain IP address CueServer and your computer
from the router to be configured manually after
during startup. startup (see step 3).
D0470B 10/20/2017
CueServer 2 Pro (CS-900)

Quick Start Guide

5-Way Menu Nav Switch
RS-485, RS-232
Digital Outputs
Contact Closure Inputs
Memory Card
2
Apply power to CueServer.
4
User Defined RGB LED Function Buttons
Bi-directional DMX Modules
w/ configurable jack types (optional)
3
Your CueServer 2 is now ready to use.
Download and install CueServer Studio 2 software to start editing content
in the CueServer. It is available for both Mac OS X and Windows, and it may
be downloaded from www.cueserver.com/download.
CueServer 2 user's manual is available online at www.cueserver.com/manual.
For more information about CueServer 2, visit www.cueserver.com.
Interactive Technologies, Inc.
5295 Lake Pointe Center Drive, Suite 100
Cumming, GA 30041 USA
www.interactive-online.com
This step only applies if you chose option B in step 1.
The default (factory) IP address of CueServer is 10.0.1.234.
The IP address of your computer will need to be changed to
something that belongs to the same subnet as your CueServer,
or vice-versa. Use the menu buttons to change the IP address
of CueServer.
The first three fields of the IP address will need to match the IP
address of the CueServer and the fourth field will need to differ
from the one used by CueServer, while being within 1 - 254
range.
In the default IP example, it would be 10.0.1.235.
What's Included:
• CS-900 Processor
• Power Supply
• Rack Mount Ears (2x)
• Rubber Feet (4x)
• A Lot of Love and Care
CueServer 2 can be
used to meet
California Title 24
requirements.
CueServer 2 is proudly
designed, engineered,
and manufactured in
the USA.
