Forest lighting FL-ALC-90WXXK-YYZZ Installation Instructions Manual

SERIES:
FL-ALC-90WXXK-YYZZ
FL-ALC-150WHXXK-YYZZ
FL-ALC-300WXXK-YYZZ
Model number parameter list:
Item Model
A FL-ALC-90WXXK-YYZZ
C FL-ALC-120WXXK-YYZZ
D FL-ALC-150WXXK-YYZZ
E FL-ALC-150WHXXK-YYZZ
F FL-ALC-220WXXK-YYZZ
G FL-ALC-220WHXXK-YYZZ
H FL-ALC-300WXXK-YYZZ
I FL-ALC-300WHXXK-YYZZ

1. Introduction

 This LED Flood light uses the latest in solid state lighting technology for long life, low
maintenance, and high efficiency.
 The same as traditional HID lighting. There are two installation methods, suitable for various
occasion.
 An internal power-factor-corrected switch-mode supply allows it to be used from
any nominal 100-277V, 60Hz AC supply without any variation in light output.
 Suitable for use in the following conditions:
• Ambient Temp: -20~+40°C
• Wet Locations
Note: Save these instructions for future reference.
2. Installation
Warning:
To avoid the risk of fire, explosion, or electric shock, this product should be installed,
inspected, and maintained by a qualified electrician only, in accordance with all applicable
electrical codes.
Forest Lighting, 2252 Northwest Pkwy SE, Suite D, Marietta, GA 3006.
;
FL-ALC-120WXXK-YYZZ
;
FL-ALC-220WXXK-YYZZ
;
FL-ALC-300WHXXK-YYZZ
Input Voltage
100-277VAC
100-277VAC
100-277VAC
277-480VAC
100-277VAC
277-480VAC
100-277VAC
277-480VAC
INSTALLATION INSTRUCTION MANUAL
LED AREA LIGHT, 100-277VAC&277-480V
;
FL-ALC-150WXXK-YYZZ
;
FL-ALC-220WHXXK-YYZZ
;
Power
Watt
Factor
90W
120W
150W
150W
≥0.9
220W
220W
300W
300W
