Jenn-Air JEF3115G Planning Dimensions

JENN-AIR
®
15" MODULAR ELECTRIC GRIDDLE
JEF3115G – 15" x 5

PRODUCT DIMENSIONS

A
A
Top View
D*
D*
Front View
B
B
G
G
G
H
H
Side View
IMPORTANT: Dimensional specifications are provided for planning purposes only.
Do not make any cutouts based on this information. Refer to the Installation Guide before
selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All Jenn-Air appliances are appropriately UL, CUL or CSA approved.
®
DETAILED PLANNING DIMENSIONS
⁄ " x 21"
13
32
A
B
B
B
F
F
E
F
E
E
C
C
C
D*
B
I
I
J
I
J
J
H
MODEL #
A Overall width
B Overall depth
Center of cooktop to center of
C
electrical conduit
D* Width of cooktop base
Height from electrical conduit to
E
underside of cooktop
F Thickness of cooktop surface
Height from underside of cooktop base
G
to top of control knob
H Depth of cooktop base
I Height of cooktop base
Height from bottom of electrical
J
conduit to underside of cooktop base
* Measured from tab to tab. Tabs should not be bent during installation.
1 of 2
JEF3115G
in cm
15 38.1
21 53.3
5 ⁄ 14.2
39
64
14 ⁄ 36.3
19
64
5 ⁄ 13.7
13
32
1 ⁄ 3.2
1
4
5 ⁄ 14.0
1
2
20 ⁄ 51.6
19
64
4 ⁄ 10.8
1
4
1 ⁄ 3.2
1
4
