CHADLESS AUTOMATIC LETTER OPENER

Specifications

Functional

Maximum Envelope Size..........................................................................................4.25" X 9.5"

Speed...............................................................................................12,000/Hour #10 Envelope

Load Capacity...........................................................................................................................5"

Physical

Letter Opener Dimensions.......................................................................20.25" X 10.5" X 11.5"

Machine Weight...............................................................................................................22 Lbs.

Electrical

Power.........................................................................................................115 V.A.C. 50/60 Hz.

WARNING! Never connect power to the machine until you are ready to set up and

operate the Letter Opener.

hands, hair, loose clothing, and jewelry away from all moving parts. Serious bod-

ily injury could result. Service, or disassembly of letter opener should only be

attempted with the power disconnected and locked out.

1.0

Features

*Chadless design cuts only one side of the envelope, leaving no scrap

*Automatic on feature turns the opener 'on' and 'off' as needed

*Easy assembly, set-up, and operation

*Low maintenance operation

*Minimal user adjustments during ordinary use

*Automatic feeding assures operation is as easy as placing a stack of envelopes on the open-

er and turning it on.

*Power light tells the operator at a glance if the main power is on

MODEL 1648

During set up, operation, and maintenance keep

Need help?

Do you have a question about the 1648 and is the answer not in the manual?

Page 1 MODEL 1648 CHADLESS AUTOMATIC LETTER OPENER Specifications Functional Maximum Envelope Size..................4.25” X 9.5” Speed....................12,000/Hour #10 Envelope Load Capacity...........................5” Physical Letter Opener Dimensions...............20.25” X 10.5” X 11.5” Machine Weight.......................22 Lbs. Electrical Power......................115 V.A.C. 50/60 Hz. WARNING! Never connect power to the machine until you are ready to set up and operate the Letter Opener.
Page 2 Parts 1. Power Cord 2. Main power switch 3. Back Cover 4. Front Cover 5. Blade Cover 6. Catch Basket 7. Power Indicator 8. Cutting Blade 9. Back Up Bearing 10. Depth of Cut Adjustment 11. Retarder Pressure Adjustment 12. Retarder Pad 13.
Page 3 Operation Power Switch Turn the main power switch located on the back of the 1648 ‘on’ by placing it in the ‘I’ posi- tion. The green indicator light will come on whenever the main power is on. The unit may run momentarily when turned ‘ON’.
Page 4 3. Check that the power cord is firmly inserted into the letter opener. 4. Machine may be jammed to the point of non-running. Unplug and clear jam. 5. Electrical Malfunction-Have the 1648 checked by a qualified technician. 251 Wedcor Avenue...
