MARTINDALE MM39 Instruction Manual

SAFETY INFORMATION
MM39 MULTIMETER
The following safety information must be observed to
ensure maximum personal safety during the operation of
this meter:
Use the meter only as specified in this manual or the
I
NSTRUCTION
protection provided by the meter might be impaired.Test
M
ANUAL
the meter on a known voltage before using it to
determine if hazardous voltages are present.
Do not use the meter if the meter or test leads look
damaged, or if you suspect that the meter is not
operating properly. Never ground yourself when taking
electrical measurements.
Do not touch exposed metal pipes,outlets, fixtures, etc.,
which might be at ground potential. Keep your body
isolated from ground by using dry clothing, rubber shoes,
rubber mats, or any approved insulating material. Turn off
power to the circuit under test before cutting,
unsoldering, or breaking the circuit. Small amounts of
current can be dangerous. Use caution when working
above 60V DC or 30V AC rms. Such voltages pose a
shock hazard.
When using the probes, keep your fingers behind the
finger guards.
Measuring voltage which exceeds the limits of the
multimeter may damage the meter and expose the
operator to a shock hazard. Always observe the meter
MARTINDALE
voltage limits as stated on the front of the meter.
E L E C T R I C
Trusted by professionals
SPECIFICATIONS
Display: 3½ digit liquid crystal display (LCD) with a
maximum reading of 1999
Polarity: Automatic, positive implied, negative polarity
indication
Overrange: (OL) or (-OL) is displayed
Zero: Automatic
Low battery indication: The " " is displayed when the
battery voltage drops below the operating level
Measurement rate: 2 times per second, nominal
Auto power off: Approx. 10 minutes
Operating environment:
0°C to 50°C at < 70% relative humidity
Storage temperature:
-20°C to 60°C at < 80% relative humidity
Accuracy:
Stated accuracy at 23°C ± 5°C, <75% relative humidity
Temperature Coefficient: 0.1 × (specified accuracy)
per °C. (0°C to 18°C, 28°C to 50°C)
Altitude: 6561.7 Feet (2000m)
Power: 1.5V batteries x2, R03/SIZE AAA
Battery life: 200 hours typical with carbon-zinc
Dimensions: 145mm (H) × 70mm (W) × 34mm (D)
Weight: Approx. 11.1 oz. (315g) including holster
Accessories: One pair test leads, 1.5V battery x2
(installed) and Operating Instructions
DC VOLTS
Ranges: 200mV, 2V, 20V, 200V, 600V
Resolution: 0.1mV
Accuracy: ±(1.0% rdg + 2 dgts)
Input impedance: 200mV: >100MΩ: 2V:10MΩ
20V ~ 600V:9.1MΩ
Overload protection: 600VDC or AC rms
AC VOLTS (50Hz - 500Hz)
Ranges: 200mV, 2V, 20V, 200V, 600V
Resolution: 0.1mV
Accuracy:
±(2.0% rdg + 5 dgts) 50Hz ~ 100Hz on 200mV range
±(2.0% rdg + 5 dgts)
Input impedance: 200mV:>100MΩ: 2V:10MΩ
20V ~ 600V:9.1MΩ
Overload protection: 600V DC or AC rms
CURRENT
Ranges: 10A
Resolution: 0.01A
DC accuracy: ± (3.0% rdg + 3 dgts)
AC accuracy: (50Hz ~ 500Hz) ± (3.5% rdg + 5 dgts)
Voltage burden: 0.2V
Input protection:10A/500V fast blow ceramic fuse
RESISTANCE
Ranges: 200Ω, 2kΩ, 20kΩ, 200kΩ, 2MΩ, 20MΩ
Resolution: 0.1Ω
Accuracy:
±(1.5% rdg + 4 dgts) on 200Ω to 200kΩ ranges
±(2.5% rdg +4 dgts) on 2MΩ range
±(5.0% rdg + 5 dgts) on 20MΩ range
Open circuit volts: -0.45Vdc (-1.2Vdc on 200Ω range)
Overload protection: 500V DC or AC rms
DIODE TEST
Test current: 1.0mA (approximate)
Accuracy: ±(3.0% rdg + 3 dgts)
Resolution: 10mV
Audible indication: <0.25V
Open circuit volts: 3.0Vdc typical
Overload protection: 500VDC or AC rms
CONTINUITY
Audible indication: Less than 25Ω
Response time: 500ms
Overload protection: 500VDC or AC rms
