DC Outdoor Power Supply/Chargers

Installation Guide

Models Include:
WayPoint3
- 2.5A @ 12VDC or 24VDC.
- 115/230VAC input.
WayPoint5
- 3.5A @ 12VDC or 24VDC.
- 115/230VAC input.
WayPoint1012V
- 10A @ 12VDC.
- 230VAC input.
Rev. 080911DCPL
WayPoint7
- 6A @ 12VDC or 24VDC.
- 115VAC input.
WayPoint7V
- 6A @ 12VDC or 24VDC.
- 230VAC input.
WayPoint104
- 10A @ 24VDC.
- 115VAC input.
More than just power.™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WayPoint3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Antronix WayPoint3

  • Page 1: Installation Guide

    DC Outdoor Power Supply/Chargers Installation Guide Models Include: WayPoint3 WayPoint7 - 2.5A @ 12VDC or 24VDC. - 6A @ 12VDC or 24VDC. - 115/230VAC input. - 115VAC input. WayPoint5 WayPoint7V - 3.5A @ 12VDC or 24VDC. - 6A @ 12VDC or 24VDC.

  • Page 2: Specifications

    [G] (Fig. 2-4, pgs. 4-6). Wire gauge range of connectors is 14 AWG to 11 AWG (1.6 mm to 2.5 mm diameter). 7. Select the desired DC output voltage by setting SW1 to the appropriate position for models WayPoint3, WayPoint5, WayPoint7, and WayPoint7V (Reference Chart above) (Fig.

  • Page 3: Terminal Identification

    CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. Terminal Identification: Terminal Legend Function/Description WayPoint3: 12VDC or 24VDC @ 2.5A supply current. WayPoint5: 12VDC or 24VDC @ 3.5A supply current.
  • Page 4 Fig. 2 - WayPoint3, WayPoint5, WayPoint7, and WayPoint7V. Fig. 2a OFF - 24V ON - 12V OFF - 24V ON - 12V Fig. 2b AC DC 5A 250V --- BAT + --- DC + CAUTION HIGH VOLTAGE Fig. 2c --- BAT +...
  • Page 5 Fig. 3 - WayPoint1012V --- DC + Fig. 3a 5A 250V BAT FAIL NC C NO NC C NO AC FAIL CAUTION HIGH VOLTAGE + BAT --- Fig. 3b DC Outdoor - 5 -...
  • Page 6 Fig. 4 - WayPoint104 Fig. 4a AC DC 5A 250V C NO NC C --- BAT + --- DC + CAUTION HIGH VOLTAGE Fig. 4b --- BAT + --- DC + - 6 - DC Outdoor...
  • Page 7 Wall Mount Installation 1- Place unit at desired location and secure with mounting screws (not included) (Fig. 5, pg. 7). Fig. 5 Pole Mounting Using Optional Pole Mount Kit PMK1 (not included): This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 is in- tended for use with Altronix outdoor rated power supplies or accessories housed in WP1, WP2, WP3 and WP4 enclosures.
  • Page 8 Enclosure Dimensions (H x W x D): 13.32” x 11.32” x 5.6” (338.28mm x 287.528mm x 142.24mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A. IIWayPointDC Series B07Q MEMBER...
