POWERLINE

Solar Battery

User's Manual

PV- - - - 1 1 1 1

SolarUM.2/05.Rev.0

Table of Contents

Need help?

Do you have a question about the 6-85F-25S and is the answer not in the manual?

Questions and answers

Summary of Contents for Powerline 6-85F-25S

Page 1 POWERLINE POWERLINE POWERLINE POWERLINE PV- - - - 1 1 1 1 Solar Battery Solar Battery Solar Battery Solar Battery User’s Manual User’s Manual User’s Manual User’s Manual SolarUM.2/05.Rev.0...
Page 2: Table Of Contents
Table of Contents Precautions ....................2 Installation ..................... 3 Adding Water....................5 Hydrometer....................6 Voltage ......................6 Specific Gravity ..................... 8 Record Keeping..................... 8 Equalize Charge.................... 9 Sulfated Batteries ..................9 Battery Characteristics ................11 Diagrams ..................... 12 Figures ......................13 Troubleshooting...................
Page 3: Precautions
PRECAUTIONS NEVER smoke or produce a spark in the battery area. When performing battery maintenance wear safety glasses, rubber gloves and protective clothing. When using a hydrometer avoid letting the rubber tube shake as this can cause drops of electrolyte to splash onto your clothing or into your eyes. Store your hydrometer in a clean dry place.
Page 4: Installation
INSTALLATION – Continued STEP 2 Inspect the battery and tray for evidence of damage, if damage has occurred file a claim with the carrier immediately. If you see liquid on the top of the cells pour some neutralizing agent into a small container and apply with a clean paint brush.
Page 5 INSTALLATION – Continued WARNING: The weight inside the plastic cells will cause the sides to bulge when removed from the tray. This is normal, however, use caution when handling the cells. Any pressure on the sides will cause the cells to “breathe”...
Page 6: Adding Water
INSTALLATION – Continued STEP 10 Install the lid by taping the hinge pin back into the can hole. When you install the lid you have a choice of where the hinges are located. Some lid hinges use an internal hex head bolt, use an Allen wrench to remove and replace the lid.
Page 7: Hydrometer
HYDROMETER Insert the rubber tip into the cell but not into the electrolyte. Squeeze the bulb and lower the rubber tip into the electrolyte and release the pressure from the bulb. The barrel will fill up and the float will rise. It is very important for the float to be freely suspended in the electrolyte.
Page 8 VOLTAGE – Continued FULLY CHARGED VOLTAGE READINGS On-charge voltage readings are most informative and are good indicators of battery condition. These readings should be taken when the battery is approaching full charge with 2% of the battery capacity flowing into the battery. New batteries, when fully charged and 2% of the battery capacity flowing into the battery, will have cell voltages between 2.55 –...
Page 9: Specific Gravity
SPECIFIC GRAVITY The standard fully charged specific gravity for the HAWKER PV-1 Solar Battery is 1.275 – 1.285 at 77˚ F (see Fig. 4 and Fig. 5 on page 14) and the 100% discharged gravity is 1.140. Since the acid content of the electrolyte decreases linearly as the cell is discharged, the decrease in gravity is directly proportionate to the amount in ampere-hrs taken out.
Page 10: Equalize Charge
EQUALIZE CHARGE The term “equalize” simply means a controlled overcharge. This procedure is used to adjust the difference between cells that develop due to temperature variations within the battery, manufacturing, and cycling of the battery. The equalize charge will also help scrub off sulfate particles that tend to build up on the battery’s positive plate.
Page 11 SULFATED BATTERIES – Continued Cells of a sulfated battery give a low specific gravity and voltage reading and the battery will not become fully charged after a regular equalize charge. Before assuming that the battery is sulfated, rule out the possibility that low specific gravity may be due to acid loss.
Page 12: Battery Characteristics
BATTERY CHARACTERISTICS...
Page 13: Diagrams
DIAGRAMS...
Page 14: Figures
FIGURES Freezing Points of Specific Gravity vs. Battery Electrolyte Percent Discharged Specific 1.280 Centigrade Fahrenheit Gravity 1.000 1.260 1.050 -3.3 1.100 -7.7 1.240 1.125 1.150 1.175 1.220 1.200 1.210 1.200 1.220 1.230 1.180 1.260 1.270 1.160 1.280 1.290 1.140 Cell Specific Gravity 1.120 Temperature...
Page 15: Troubleshooting
TROUBLESHOOTING PROBLEM PROBABLE CAUSE REMEDY Battery not 1. Battery is undersized 1. Replace with a larger battery performing as 2. Battery not fully charged 2. Check charger and controller expected. 3. Weak or defective cells 3. Perform a load test 4.
Page 16: Specifications
Specific Gravity @ 77˚ F 1.285-1.275 Fully Charged 1.160 80% Discharged Model # Breakdown Example: 6-85F-17S 6 cells per Tray 85 amps per positive plate F represents Powerline 17 plates total (8 pos. & 9 neg) PV-1 Solar Battery Photo is a 12-85F-13 battery.
Page 17: Maintenance
MAINTENANCE WEEKLY 1. Record hydrometer reading of pilot cell (the cell with the lowest specific gravity when you first received the battery). Once a year select a different cell to be the pilot cell. 2. Check the water level (add as needed). 3.
Page 18: Records
RECORDS ENTERING DATA IN THE WEEKLY FORMS It is essential that you label each cell for these records to aid in the operation of your battery. This form is designed to enter general battery information on a weekly basis and will, at a glance, show any abnormalities in the battery’s health.
Page 19 WEEKLY CELL DATE SP. GR. A/H USED CELL TEMP. W.E.C. VOLTAGE...
Page 20 WEEKLY CELL DATE SP. GR. A/H USED CELL TEMP. W.E.C. VOLTAGE...
Page 21 WEEKLY CELL DATE SP. GR. A/H USED CELL TEMP. W.E.C. VOLTAGE...
Page 22 WEEKLY CELL DATE SP. GR. A/H USED CELL TEMP. W.E.C. VOLTAGE...
Page 23 WEEKLY CELL DATE SP. GR. A/H USED CELL TEMP. W.E.C. VOLTAGE...
Page 24 WEEKLY CELL DATE SP. GR. A/H USED CELL TEMP. W.E.C. VOLTAGE...
Page 25 WEEKLY CELL DATE SP. GR. A/H USED CELL TEMP. W.E.C. VOLTAGE...
Page 26 WEEKLY CELL DATE SP. GR. A/H USED CELL TEMP. W.E.C. VOLTAGE...
Page 27 WEEKLY CELL DATE SP. GR. A/H USED CELL TEMP. W.E.C. VOLTAGE...
Page 28 WEEKLY CELL DATE SP. GR. A/H USED CELL TEMP. W.E.C. VOLTAGE...
Page 29 WEEKLY CELL DATE SP. GR. A/H USED CELL TEMP. W.E.C. VOLTAGE...
Page 30 MONTHLY CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage...
Page 31 MONTHLY CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage...
Page 32 MONTHLY CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage...
Page 33 MONTHLY CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage...
Page 34 MONTHLY CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage...
Page 35 MONTHLY CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage...
Page 36 MONTHLY CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage...
Page 37 MONTHLY CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage...
Page 38 MONTHLY CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage...
Page 39 MONTHLY CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage...
Page 40 MONTHLY CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage...
Page 41 MONTHLY CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage CELL SP. GR. Cell Voltage...
