Mannix IRT6 Operation Manual

Congratulations on your purchase of the • The meter is pre-set to measure objects
Mannix Infrared Thermometer, model IRT6. with an emissivity of 0.95. This will accom-
The compact size lets you get into tight places modate the majority of items measured
while its convenient laser targeting and high without compensating for higher or lower
distance-to-spot ratio give you accurate read- value. In most cases there will be little dif-
ings on distant targets . ference in measurements, even if an object's
emissivity is higher or lower than this
• Precise non-contact Measurements pre-set value. Compare and confirm with
• Automatic Data Hold known values if in doubt.
• Laser Target Pointer
! Use extreme caution when the laser beam is
turned on.
! Do not point the laser toward the eyes or face
of a person or animal. Laser's potential to
cause damage is retained for hundreds of
feet.
! Be careful not to let the beam on a reflective
surface strike your eye.
• The meter provides simple one hand opera-
! Do not use near any flammable items or
tion and time saving temperature measure-
gases.
ment. Be sure the measured object fills the
"spot" seen by the aperture.
FRONT PANEL DESCRIPTION
• There will be a delay of approximately one
second between the time you initially press
the button and the time the display comes
on.
• Not recommended for measuring on shiny
surfaces. The smaller the target, the closer
the unit should be to it. To avoid thermal
shock, do not store the meter below freez-
ing.
1
SPECIFICATIONS
Measuring Range: -4 to 788˚F (-20 to 420˚C)
Resolution: 1˚F (1˚C)
Accuracy: ±3˚C or ±3%
(whichever is greater)
Accuracy Notes:
1) Accuracy stated is for ambient temperature
CAUTION
2) Accuracy stated is for emissivity of 0.95
Emissivity: 0.95 fixed
Distance Factor: D:S = Approx. 8:1
Sampling Rate: 500 m/sec.
Display: LCD display with backlight
Power Off: Automatic shut off after 8 seconds
Operating Temp.: 32 to 122˚F (0 to 50˚C)
Operating Humidity: Maximum of 80% RH
Power Supply: 9-Volt Battery
Power Current: Approx. 12mA DC
Display Size: 0.75" x 1.375"
1. IR Sensor
Weight: 6.3 oz. (178g)
2. Laser Pointer Beam
Dimensions: 6.14" x 2.1" x 1.3"
3. LCD Display
4. Backlight Select Key
5. Laser Key
6. Measure Key
2 3
D. Measurement Considerations
INDICATOR
While holding the meter, point the IR Sensor
1
toward the object whose temperature is to be
2
8.8.8 measured. The meter automatically compen-
sates for temperature deviations from ambient
˚F
3
temperature.
BAT
4
1. Laser Icon
Keep in mind that it will take up to 30 minutes
2. Digital Readout
to adjust to wide ambient temperature
3. ˚C (Celsius)
changes. When low temperatures are to be
4. ˚F (Fahrenheit)
measured followed by high temperature meas-
5. BAT (battery indicator)
urements, some time (several minutes) is
required after the low (and before the high)
MEASUREMENT OPERATION
temperature measurements are made. This is
A. Power ON/OFF
a result of the cooling process which must take
The meter automatically powers up when the
place for the IR sensor.
MEASURE key is pressed. Press the MEASURE
key to read the measured temperature on the
LCD. The meter powers off automatically
approximately 8 seconds after the MEASURE
key is released.
A flashing display is the indication that the bat-
B. Backlight LCD
tery voltage has fallen into the critical region
Select backlight by first pressing the MEA-
(6.5 to 7.5 V). Reliable readings can be
SURE key and then pressing the BACKLIGHT
obtained for several hours after the first
key. Repeat the procedure to turn the back-
appearance of the low battery indication.
light off.
Open the Battery Compartment and remove the
C. Laser Pointer
battery, then install a new battery and replace
To turn the laser pointer on, press the LASER
the cover.
key while pressing the MEASURE key. Repeat
the procedure to turn the laser OFF
4
TROUBLESHOOTING
? Meter does not turn on - Check voltage and
relace low battery. Or check time delay which
is allowed 1 second for data to appear on-
screen.
? Data flashing or laser comes on but no
data appears - Check battery voltage and
then replace low battery.
? Dashes appear on-screen - Check extreme
temperature, measure surrounding area to
see if the target exceeds the limit.
MAINTENANCE
Case cleaning:
Clean the exterior housing of the unit with a
damp cloth (use caution). Ensure no water or
BATTERY REPLACEMENT
soap is allowed inside the meter or on the
infrared lens.
Lens cleaning:
WARNING: We recommend cleaning the lens
periodically to ensure the reading accuracy. To
remove any particles on the lens use low pres-
sure compressed. If the contamination cannot
be removed with air, use a soft cotton swab.
The swab should be slightly damp and very
light pressure should be applied. Do not use
solvents to clean the lens.
5 6
