Summary of Contents for MS Electronics DMX-HS84
- Page 1 U S E R M A N U A L HDMI Splitter 1x8 DMX-HS84 Enjoy the vivid world! INTRODUCTION...
- Page 2 Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of HDMI Converters, switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient, more comfortable, more productive and more cost-efficient.
- Page 3 The accessories with the machines lists as picture： 1、5V Power Adapter 2、one pc of Manual Power Adapter Physical Connection Showing Picture： Figure 1.0 Front Panel Showing Picture L1-L8： HDMI output led status light RESET ：Reset Button Input： HDMI input led status light 0N/0FF: On Is Turn On The Device,Off Is Turm Off On The Device Figure 1.1 rear panel showing picture DC 5V: 5V DC-DC power interface...
- Page 4 Connect 5V power supply to the HDMI 1x8 Splitter. SPECIFICATIONS: DMX-HS84 HDMI resolution ……………………………..24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i Support video color format ……………………...……..….……..24bit/deep color 30bit,36bit, 48bit Support audio format……..….DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD HD(HBR) Max bandwidth……………………………………………………….………………………….340MHz Max baud rate…………………….………………….………………………………………..10.2Gbps Input/Output TMDS signal ………….…………………………..………... …..0.5~1.5Volts p-p(TTL) Input/Output DDC signal ……………………………………………..……...……… 5Volts p-p (TTL) Input cable distance..…...
- Page 5 Erosive, and oxidative environment. 2. All parts will be free from the strong shake, hit, fall. 3. Touching the power adaptor with the wet hands is prohibited. 4. Pls hold the power adaptor head and do not pull the power cord when cut off from the socket.
