RG-1000e Remote Gateway

User Guide

June 2018
R2.2.2 v2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG-1000e and is the answer not in the manual?

Questions and answers

Summary of Contents for SmartPTT RG-1000e

  • Page 1: User Guide

    RG-1000e Remote Gateway User Guide June 2018 R2.2.2 v2...

  • Page 2: Table Of Contents

    3 Installation and connection 3.1 Front panel 3.2 Rear panel 3.3 Fisrt time settings, connection and operation check 4 Examples of using RG-1000e 4.1 Conventional Mode 4.2 Capacity Plus legacy trunking network 4.3 Capacity Plus trunking network with NAI Data (hybrid mode) 4.4 Capacity Plus multi-site trunking network with NAI Data (hybrid mode)

  • Page 3: Foreword

    Trademarks MOTOROLA SOLUTIONS, the Stylized M logo, MOTOTRBO are registered in the US Patent & Trademark Office. SmartPTT and RG-1000e are the property of Elcomplus. All other product or service names are the property of their respective owners. RG-1000e Remote Gateway R2.2.2 v2...

  • Page 4: Revision History

    Revision history The following table contains the history of updates to the RG-1000e Remote Gateway user guide. Date Version Description May, 2017 RG-1000e Remote Gateway, R1.0 Initial version. July, 2017 RG-1000e Remote Gateway, R1.1 Updated release. October, 2017 RG-1000e Remote Gateway, R2.0 Updated release.

  • Page 5: Compliance With International Standards

    This device complies with EN55032/CISPR32 EN55024/CISPR24. This device complies with DIRECTIVE 2011/65/EU (RoHS 2) This device complies with IEC/EN60950-1. This device complies with TR EAC 020/2011 "Electromagnetic compatibility of technical means", GOST CISPR32- 2015, GOST CISPR 24-2013. RG-1000e Remote Gateway R2.2.2 v2 User Guide...

  • Page 6: Introduction

    Introduction This user guide describes the purpose, characteristics, functioning principles, setup and configuration of RG- 1000e . This guide is aimed at engineers responsible for installation and maintenance of the SmartPTT dispatch system and the MOTOTRBO equipment. It is assumed that users responsible for setting up RG-1000e are familiar with the following: ·...

  • Page 7: System Purpose

    USB interface. The RG-1000e with firmware version R2.2 or later may be used for connection of non-Mototrbo radios to the SmartPTT radioserver. Mobile radios and\or repeaters (analog or digital) are connected to the RG-1000e using 5 wires: PTT, CSQ, RX Audio, TX Audio and GND.
  • Page 8 Fig. 2 non-MOTOTRBO control stations: remote connection to SmartPTT dispatch system RG-1000e Remote Gateway R2.2.2 v2 User Guide...

  • Page 9: System Structure

    Ethernet interface with the cable type autodetection. To provide interaction between the system components, the RG-1000e and the radioserver are assigned static IP addresses and TCP and UDP/RTP port numbers. They are used for sending radio control commands and audio transmissions from the dispatch console. The RG-1000e can be used in the following cases: ·...

  • Page 10: Technical Specification

    2.1 Technical specification Technical parameters of the RG-1000e are listed in the following table Table 1 RG-1000e technical parameters Network interface parameters Connector RJ45 Standard 10BASE-T (IEEE 802.3) / 100BASE-TX (IEEE 802.3u) Supported TCP/IP protocols UDP, ICMP, IPv4, ARP Transmission rate—10/100 Mbps Operation mode auto-selection Operation mode—duplex/half-duplex...
  • Page 11 –4° to 140°F (–20° to +60°C) Relative humidity Up to 85% at 86°F (30°C) Operating hours 24x7 Control terminal Interface port USB 1.0 (12 MBps), Device port Software RG-1000e Customer Programming Software (RG-1000e CPS) RG-1000e Remote Gateway R2.2.2 v2 User Guide...

  • Page 12: Delivery Set

    —4 pcs., · USB cable A-miniB, 1 m. —1 pcs. * One interface cable is included in the RG-1000e delivery set (for MOTOTORBO DM 4600e/DM 4400e, XiR M8600i, DGM 8000e/DGM 5000e radio families). Optionally, an additional interface cable can be purchased.

  • Page 13: Installation And Connection

    3.1 Front panel 3 Installation and connection 3.1 Front panel The following figure shows the front panel of the RG-1000e . Fig. 3 Front panel of the RG-1000e GATEWAY POWER: The power button RADIO 1, RADIO 2, LINK: LED indicators. Their functions are presented in the following table:...

  • Page 14: Rear Panel

    RADIO 2: Socket for the second radio. The pin numbering is provided in Appendix TERMINAL: USB Mini Type-B socket for connecting to the computer and configuring the RG-1000e . POWER: Socket for power supply (11-15 VDC). GND ( ): Grounding bolt (M4).

  • Page 15: Fisrt Time Settings, Connection And Operation Check

    RG-1000e can be placed on its rubber feet or can be attached to any vertical or horizontal surface. For rigid mounting to surfaces, use the brackets from the delivery set. A radio can be fixed on the upper cover with a standard radio bracket.
  • Page 16 Fig. 6 Enable\Disable getting pow er from a connected Mototrbo radio If you clear the check box for both radios, the RG-1000e w ill be pow ered only via the Pow er socket. Ensure that Pow er socket delivers pow er to the RG-1000e before turning off the option on both radios.
  • Page 17 12. Run the SmartPTT radioserver. Wait for 3-5 minutes. 13. Check the LEDs on the front panel of the RG-1000e . If the LINK LED is constantly on and at least one Radio LED is Off, the installation and configuration have been successfully completed.

  • Page 18: Examples Of Using Rg-1000E

    4.1 Conventional Mode 4 Examples of using RG-1000e 4.1 Conventional Mode Fig. 7 Coventional m ode (digital) Fig. 8 Conventional Mode (digital + analog) RG-1000e Remote Gateway R2.2.2 v2 User Guide...
  • Page 19 4.1 Conventional Mode Fig. 9 Conventional Mode Repeater sam ple 1 Fig. 10 Conventional Mode Repeater sam ple 2 RG-1000e Remote Gateway R2.2.2 v2 User Guide...
  • Page 20 The figures above show examples of building a system between radios in Conventional Mode. In these examples the RG-1000e manages two control radios, each of which operates on its individual frequency channel and can be programmed to operate both in digital and analog modes. If dispatchers need to operate on more than two frequency channels simultaneously, more RG-1000e s with radios can be connected to the radioserver.

  • Page 21: Capacity Plus Legacy Trunking Network

    4.1 Conventional Mode 4.2 Capacity Plus legacy trunking network The topology of the dispatch system based on the SmartPTT software in the Capacity Plus Legacy trunking network without the use of the MOTOTRBO Network Application Interface protocol (hereinafter the NAI protocol) is called Capacity Plus Legacy.The following figure shows the typical topology:...

  • Page 22: Capacity Plus Trunking Network With Nai Data (Hybrid Mode)

    Private Calls to subscribers. In the example above three control stations are used for initiating and receiving Group Calls to Talkgroups 1, 2, and 4. Radio station 4 is used for initiating Private Calls to subscribers and receiving Private Calls from them. RG-1000e Remote Gateway R2.2.2 v2 User Guide...
  • Page 23 4.3 Capacity Plus trunking network with NAI Data (hybrid mode) For more information on control station configuration in the Capacity Plus Hybrid mode, see "MOTOTRBO SYSTEM PLANNER" (the “System Topologies” chapter) and the "SmartPTT Radioserver Configurator" software help file. RG-1000e Remote Gateway R2.2.2 v2...

  • Page 24: Capacity Plus Multi-Site Trunking Network With Nai Data (Hybrid Mode)

    Fig. 14 Capacity Plus Multi Site in Hybrid m ode: connection via the pool of the rem ote control stations For more information on control station configuration in the Linked Capacity Plus Hybrid mode, see "MOTOTRBO SYSTEM PLANNER" (the “System Topologies” chapter) and the "SmartPTT Radioserver Configurator" software help file.

  • Page 25: I\O Mode

    4.4 Capacity Plus multi-site trunking network with NAI Data (hybrid mode) 4.5 I\O mode RG-1000e s with firmware R2.2 and later may be used for connection of non-MOTOTRBO radios to the SmartPTT radioserver. Mobile radios and/or repeaters (analog or digital) are connected to the RG-1000e using five wires: PTT, CSQ, RX Audio, TX Audio, and GND.
  • Page 26 If the connected control station does not an output CSQ/COR/TG-Detect/PL-Detect signal line, you can use the RG-1000e built-in RX VOX for generating the CSQ signal. For example, this option is useful for connection of the MTM5000 family radios that are not equipped with the CSQ output signal line.

  • Page 27: Bridge Mode

    It creates a simple "geographically distributed" repeater. In the Bridge Mode, mobile radios and/or repeaters (analog or digital) are connected to the RG-1000e using five wires: PTT, CSQ, RX Audio, TX Audio and GND. The Bridge Mode does not support any signaling systems (CTCSS, DQS, MDC1200, QT, Select V, DMR, dPMR) and does not use digital links (USB, RS-232) to exchange commands with radios/repeaters.

  • Page 28: Storage And Transportation Conditions

    · The equipment is protected from the direct precipitation and dust. If the RG-1000e equipment is transported by air, it must be put in a pressurized compartment. It is prohibited to turn over or throw the package with the RG-1000e equipment during handling and carriage. RG-1000e Remote Gateway R2.2.2 v2...

  • Page 29: Manufacturer Warranty

    Elcomplus, at its option, will at no charge either repair RG-1000e (with new or reconditioned parts), replace it (with a new or reconditioned RG-1000e ), or refund the purchase price of the RG-1000e during the warranty period provided it is returned in accordance with the terms of this warranty. Replaced parts or boards are warranted for the balance of the original applicable warranty period.

  • Page 30: What This Warranty Does Not Cover

    · RG-1000e , which has had the serial number removed or made illegible. · Freight costs to the repair depot. · RG-1000e which, due to illegal or unauthorized alteration of the software/firmware in the RG-1000e , does not function in accordance with Elcomplus published specifications.

  • Page 31: Appendix I Pin Numberings And Diagrams Of The Interface Cables

    Appendix I Pin numberings and diagrams of the interface cables Fig. 20 RG-1000e - MOTOTRBO XPR5***e\DM4***e\XiRM8***e\DGM8***e connection cable schem atic ver 1 RG-1000e Remote Gateway R2.2.2 v2 User Guide...
  • Page 32 Fig. 21 RG-1000e - MOTOTRBO XPR5***e\DM4***e\XiRM8***e\DGM8***e connection cable schem atic ver 0 RG-1000e Remote Gateway R2.2.2 v2 User Guide...
  • Page 33 Fig. 22 RG-1000e - XPR2500 \ DM2600 \ XiRM6660 \ DEM500 connection cable shem atic ver 1 RG-1000e Remote Gateway R2.2.2 v2 User Guide...
  • Page 34 Fig. 23 RG-1000e - XPR2500 \ DM2600 \ XiRM6660 \ DEM500 connection cable shem atic ver 0 RG-1000e Remote Gateway R2.2.2 v2 User Guide...
  • Page 35 Fig. 24 RG-1000e - TETRA MTM5*** connection cable schem atic RG-1000e Remote Gateway R2.2.2 v2 User Guide...
  • Page 36 Fig. 25 RG-1000e - APX\XTL connection cable schem atic RG-1000e Remote Gateway R2.2.2 v2 User Guide...
  • Page 37 Fig. 26 RG-1000e - CDM\GM\PRO connection cable schem atic RG-1000e Remote Gateway R2.2.2 v2 User Guide...

  • Page 38: Appendix Ii Mounting Elements

    Appendix II Mounting elements Mounting elements of the RG-1000e s and the radio bracket are shown in the following figure. Fig. 27 Mounting elem ents of the RG-1000e GATEWAYs and the radio bracket The mounting points of the RG-1000e brackets are shown in the following figure.

  • Page 39: Appendix Iii Power Cable Preparation

    Appendix III Power cable preparation For connecting RG-1000e to an external power supply you may build your own power cable. Next parts are needed for building RG-1000e power cable: - power connector Phoenix Con PTSM 0.5-3-P 1778845; - 3 wires power cable with conductors' size 0.4-0.5 sq.mm (21-20AWG)
  • Page 40 Fig. 30 RG-1000e pow er plug conductors connect-release RG-1000e Remote Gateway R2.2.2 v2 User Guide...
