Telldus TZWP-102 User Manual

User manual
Telldus Plug-in Switch Mini
Firmware version: v1.0
Type: TZWP-102
Item number: 315510
Z-Wave Plug-in Switch Mini. Control lighting and other electronic equipment up to 2300 W
(resistive load). The device is designed with very thin edges, making it possible to use two
devices side by side in most electical outlets. The device acts as a repeater for the Z-Wave
network.
Specification
Maximum load:
Range:
Operating temperature:
Power consumption:
Frequency:
Brand name:
Terminology
Add The process of including a node into the Z-Wave network.
Remove The process of excluding a node from the Z-Wave network.
Installation
Insert the device into the electrical outlet where it's supposed to operate. Make sure that the
product you are connecting does not draw more than 2300 Watts. Test that it's possible to
control the device manually by pressing the button.
Add device
This device can be included and operated in any Z-Wave network with other Z-Wave
certified devices from other manufacturers and/or other applications. All non-battery
operated nodes within the network will act as repeaters regardless of vendor to increase
reliability of the network.
When the device is not added to any Z-Wave network, the LED will flash slowly.
If the device already is added to a Z-Wave network, follow the remove device process before
adding it to your network. Otherwise adding this device will fail.
Automatically add device to network
When the device is inserted into an electrical outlet it's in automatical add mode (Network
Wide Inclusion, NWI). This means that the device is added automatically when the Z-Wave
controller enters add mode.
Telldus is marketed by Proove AB, Sweden
www.proove.se • +46 (0)346 715600
10A / 2300 W (resistive load)
Up to 30 meters indoor
-10 - 40°C
<1W
868.42 MHz (EU)
1 (5)
