Page 1 User Guide COVER 앞...
Page 2 User Guide...
Page 3 © Copyright 2017 Rsupport Co. Ltd. The contents of User Guide might change without notice upon improve- ment of performance or function. The limited and only warranty about RemoteMeeting BOX and the service in respect of RemoteMeeting BOX is defined in Warranty Card enclosed in the product package.
Page 4: Table Of Contents
Index Supply power to RemoteMeeting BOX ��24 Introduction to RemoteMeeting BOX �� 6 Language Selection ��25 Equipment for video conferencing and collaboration ��6 Time Zone Setting ��25 Suitable size of meeting room ��6 Network Setting ��26 Ethernet Automatic ��27 Network ��6 Ethernet Manual ��27 Display ��6 Wireless LAN ��28...
Page 5 Introduction to RemoteMeeting BOX Placing RemoteMeeting BOX RemoteMeeting BOX is handily placed on the meeting table or put on the Equipment for video conferencing and collabora- wall with a VESA mount enclosed in the package. tion Place on the table RemoteMeeting BOX is the most efficient video conferencing console to transform an existing conventional meeting room into cool space for video Camera...
Page 6 Using VESA mount to fix on the table Mount on the wall When you place RemoteMeeting BOX on the table, you may use VESA mount and Velcro set which come with the package to fix it on the contact surface. (optional) RemoteMeeting BOX VESA mount Smaller Velcro(2)
Page 7: Package Contents
Package Contents Features Top View Please check all package contents and products condition before installing hardware. If you find a problem, please consult the local Rsupport custom- er service center or the seller. RemoteMeeting BOX console remote control and batteries...
Page 8 Front View Back View 1. Power connector 1. HDMI Input port Connect AC adaptor to 1 and supply the converted DC power to Connected by HDMI cable to devices such as laptop computers with RemoteMeeting BOX. HDMI output interface. 2. Ethernet port(RJ-45) You can share the personal screen to attendees by connecting HDMI Connect a ethernet cable to 2.
Page 9: Remote Control
Remote Control Remote Control Key Functions POWER ON/OFF power, ON/OFF stand-by mode ON/OFF Arrow key Cursor up Arrow key Cursor down Arrow key Cursor left Arrow key Cursor right Selects a menu or confirms the selected operation Displays the main menu Menu Switch screen Switch screen : video meeting →...
Page 10: Device Registraion Of Remotemeeting Box
Device Registraion of RemoteMeeting BOX Dynamic key During the meeting, show / hide PIP screen Dynamic key Display meeting room list, Go to home screen You must register RemoteMeeting BOX in the admin page of remotemeet- ing.com to Numeric Key Activated when number input is required start online video conferencing.
Page 11: Getting Started(Installation)
Getting Started(installation) Connect Camera Connect camera to USB 3.0 port. Install package contents including RemoteMeeting BOX, camera, and speakerphone. Connect RemoteMeeting BOX to TV or monitor by HDMI cable and turn on the power to display screen. Install all necessary devices following guide pictures below regardless of order and push power button at the finish to get started.
Page 12 Connect Speakerphone Connect Display Monitor Connect Speakerphone to USB 2.0 port. Connect HDMI cable to HDMI port normally located in the back of display monitor. You can find more information about Jabra Speak 510 in Jabra website; http://www.jabra.com/business/speakerphones/jabra-speak-series/jabra- speak-510 RemoteMeeting BOX USER GUIDE RemoteMeeting BOX USER GUIDE...
Page 13 Connect AC Adaptor Conceptual Diagram Connect the power cable. Looks like a following picture when completed. RemoteMeeting BOX USER GUIDE RemoteMeeting BOX USER GUIDE...
Page 14: Supply Power To Remotemeeting Box
Initial Setting and Device Test Language Selection If you install all the necessary contents, supply power to RemoteMeeting BOX by pressing Power Button and start initial configuration steps. Supply power to RemoteMeeting BOX Press Power Button to supply power. Select your language with the remote control and press OK. Time Zone Setting NOTE: Standby mode and Power-off Standby mode is executed by one short pressing Power Button in power-on status,...
Page 15: Network Setting
Network Setting Ethernet Automatic When you select Ethernet automatic, IP address is automatically assigned Select a local network. as the above image. • Ethernet Automatic: IP address is automatically assigned • Ethernet Manual: Input IP address directly Ethernet Manual • Wireless LAN : Wireless network NOTE: If you don’t know the local network information, ask a network administra- tor.
Page 16: Speakerphone Wireless Connection
Speakerphone Wireless Connection Wireless LAN If you select Wireless LAN, the screen of Wireless LAN setting will appear. JABRA speakerphone can be connected to RemoteMeeting BOX with Bluetooth as well as USB cable. Select a name of preferable wireless network in the scanned list. Connect JABRA speakerphone to RemoteMeeting BOX with Bluetooth as Bluetooth connection guide on the screen.
Page 17: Speaker Test
Speaker Test Mic Test Check the speaker. Check the mic. If you hear the sound from speakerphone, click YES to move on Make a sound or talk to speakerphone. The mic bars on the screen the next step. respond with the sound. NOTE: If you do not hear the sound from the speakerphone, check the USB cable If the bars move following sound, click YES to move on the next or Bluetooth connection.
Page 18: Camera Test
Camera Test Completed Verify that camera is working properly. Congratulation! The initial setting has been completed. You are so ready to experience new culture of collaboration in Remote- Meeting BOX. If you see video screen from camera on the monitor, click YES to move on the next step.
Page 19: How To Screen Share Mode
How to Screen Share Mode Caution (sharing screen from personal device) • This product should be used with ambient temperatures between 32℉ to 104℉ You can display the screen from your laptop PC on the conference monitor • Do not disassemble the product. The manufacturer warranty will not and do the presentation for participants in both on-line and off-line local applied to the product that have been disassembled by a user.
Page 20 COVER 앞...
