ATMTrader Xcellerate Quick Start Manual

TRITON ATMS
Applicable: RL1600, RL2000, RL5000,
RT2000, FT5000
STEP 1: Terminal Configuration
ATM Communication Mode: TCP/IP
• Terminal Configuration 6. Communication
F4: Make sure "Enable SSL" is unchecked
8. Communication Protocol: TCP/IP
9. Communication Message Format:
TO TABLE 2
3. Permanent TCP/IP Connection: UNCHECK
1. Host IP Address: 192.168.1.90
2. Host IP Port: REFER TO TABLE 3
• Press Enter (1x) to Save All Changes
• Press Cancel (1x) to Return
STEP 2: Diagnostics
Define TCP/IP parameters for the ATM
• 2. Diagnostics 7. Modem / Ethernet
6. Configure Ethernet Settings
6. Enable DHCP: UNCHECK
1. IP Address: 192.168.1.91
• Press Cancel (1x) to Exit Keyboard
• Press Enter (1x) to Save
2. Subnet Mask: 255.255.255.0
• Press Cancel (1x) to Exit Keyboard
• Press Enter (1x) to Save
3. Default Gateway: 192.168.1.90
• Press Cancel (1x) to Exit Keyboard
• Press Enter (1x) to Save
• Press Enter (1x) to Return to Main Menu
• 5. System Parameters 5. Restart the
Terminal: Enter.
TABLE 1
Processors
1 ISO Processing
ST
CardTronics
Columbus Data
DNS (MoneyTree)
EFX
Elan (Genmega)
Elan (Hyosung)
Metavante
Worldpay
Switch Commerce
REFER
TABLE 2
Processors
1 ST ISO Processing
Cardtronics
Columbus Data (CDS)
DNS (MoneyTree)
EFX
Elan
Metavante
Worldpay
Switch Commerce
TABLE 3
Processors
1 ST ISO Processing
Cardtronics
Columbus Data (CDS)
DNS (MoneyTree)
EFX
Elan
Metavante
Worldpay
Switch Commerce
Instant Configuration Update
When an update is required for your wireless unit. While
the modem is ON, press and hold the reset button until
it blinks red and green to download the latest processor
configuration. Wireless unit will reboot once completed.
TCP/IP Type
Visa Framed
Visa Framed
Standard
Standard
Visa Framed
SSL Pass Through
Visa Framed
Standard
Standard
Visa Framed
Triton Message Format
Triton Standard
Triton Standard TCP/IP No CRC
Triton Standard TCP/IP No CRC
Triton Standard TCP/IP No CRC
Triton Standard TCP/IP No CRC
Triton Standard
Triton Standard TCP/IP No CRC
Triton Standard TCP/IP No CRC
Triton Standard
Host Port #1 Host Port #2
9021 9021
7004 7004
7000 7001
561 561
9000 9000
7002 7002
30000 30000
6661 6661
7003 7003

QUICK START GUIDE

XCELLERATE WIRELESS GATEWAY

Package Contents:

• Wireless Modem Unit
• Antenna
• Power Supply
• 2FT CAT5E Ethernet Cable
• Quick Start User Guide
Should any of these items be missing or damaged,
please contact ATMTrader at (855) 286-2286.
ATMTrader
2235 Auto Centre Drive
Glendora, CA 91740
CONTACT US
IT Help Desk: (909) 670-1988
Sales Desk: (855) 286-2286
