LUMENERA QUICK START GUIDE
QUICK START GUIDE
Network Camera
Thank you for purchasing a Lumenera network camera. Follow this guide for quick and easy installation. Please read the
instructions in their entirety before proceeding.

PART I: CAMERA MODEL

The exact power and lens requirements vary by camera type. The camera model (e.g. "LE165CE-DN") can be located on the
camera's white barcode label.
Standard Format (White)

PART II: CAMERA REQUIREMENTS

1. TOOLS AND PARTS

Tools required when installing with an external power
supply:
• Small screwdriver (1.8 mm) flat head
• 18 to 28 AWG wire
• Black 10-terminal locking connector (included)
(Replacement part no. Le903)

3. POWER

Refer to the power supply chart below to avoid camera damage. Lumenera includes a set of international wall plugs with
all power supplies.
Camera Model
Standard Format:
e.g. Le075CP, Le165CE, Le165CP, Le175CA, Le275CP, Le375CP, Le575CP
Le045 & Intelligent Series:
e.g. Le045CB, Li045CB, Li165CB
Li175CB Intelligent Camera:
Li175CB (only)

Power over Ethernet

PoE (IEEE 802.3af) switch or mid-span injector replace external power.

Network Connection

Cat5e twisted pair cable with RJ45 connectors, 100BASE-TX Ethernet connection.
7 CAPELLA COURT, OTTAWA, ON, CANADA K2E 8A7 | LEIPZIG, GERMANY | ATLANTA, GEORGIA, USA | TEL (613) 736-4077 | FAX (613) 736-4071 | WWW.LUMENERA.COM | INFO@LUMENERA.COM

2. LENS

Power Supply Specifications
12 to 48 V DC / 2 A / 24 W max.
24 to 48 V DC / 1 A / 24 W max.
24 V AC / DC / 1 A / 24 W max.
© 2011 Lumenera Corporation. All rights reserved.
Design, features, and specifications are subject to change without notice
0726011
Le045 & Intelligent Series (Black)
CS or C-mount Lens Optical Format Chart
Camera Model
Le045 / Li045
Le075
Le165 / Li165
Le175CA / Li175CB
Le175MP / Li175MB
Le275
Le375
Le575
Recommended Lumenera Power Supply for
PoE or
PoE or
PoE or
WWW.LUMENERA.COM
Optical Format
1/3"
1/3"
2/3"
1/3"
1/2"
1/2"
1/2"
1/2.5"
Non-PoE Applications
La21224N
(formerly Lu8501)
La22424N
(formerly Lu8401)
La22424N
(formerly Lu8401)
