- Page 1 ALLWALL ALL7008...
- Page 3 Quick Install Guide Express-Setup Version 12 2007...
-
Page 5: Hardware Configuration
Hardware Configuration Hardware Description: Power LED: Illuminates solid green when ALL7008 is first powered up. Start up takes up to one minute to complete. Status LED: When LED light start glittering, it means the system is under the status of booting. Around two minutes when the LED light stop glittering, it means the system is booting successful. -
Page 6: Software Configuration
Software Configuration STEP 1﹒Connect both the Administrator’s PC and the LAN port of ALL7008 to a hub or switch. And use a web browser to display the configurations of the ALL7008 (such as Internet Explorer or Netscape). The default IP address of ALL7008 is http://192.168.1.1... - Page 7 STEP 3﹒A pop-up screen will appear and prompt for a username and password. A username and password is required to connect to ALL7008. Enter the default login username and password of Administrator (FigureS-1). Username: admin Password: admin Click OK. FigureS-1 Login WebUI STEP 4﹒After entering the username and password, select Interface on the...
- Page 8 STEP 6﹒After entering to the main system of ALL7008, select Interface on the left menu and click on WAN. (Figure S-3) FigureS-3 WAN 1/2 Interface STEP 7﹒WAN Interface 1 / 2: select the WAN 1/2 that needs to be set and click Modify.
- Page 9 Select Interface on the left menu and click DMZ function. DMZ Interface: Select DMZ_TRANSPARENT Click OK. ALL7008 will reboot again. It takes about 2 minutes to reboot. When the LED light stop glittering, it means reboot successfully and can enter WebUI again. (FigureS-5) FigureS-5 DMZ WebUI STEP 9﹒Click on System function and click on Date/Time function in...
- Page 10 Source Address – Select “Inside_Any” Destination Address – Select “Outside_Any” Action: Select “PERMIT ” Click OK Figure S-7 Add New Policy Setting STEP 14﹒If ALL7008 access control function is being required, please refer to Policy and Address to add some settings.
- Page 11 Mail Server is in DMZ or LAN When Mail Server is in LAN or DMZ, it needs to set Mail Relay additionally. (FigureS-8) FigureS-8 Setting of Mail Server in DMZ STEP 15﹒Click on Mail Security, click on Configure and enter Mail Relay function.
- Page 12 STEP 17﹒Enter Policy Object function and select Group in Service function. STEP 18﹒Enter the following setting in Group WebUI: Name: E-mail Add New Service: DNS, POP3, SMTP Click OK to complete Group Setting (FigureS-10) FigureS-10 Complete Group Setting...
- Page 13 STEP 19﹒In Policy function, add new WAN to DMZ Policy, DMZ to WAN Policy, LAN to DMZ Policy individually. 【WAN to DMZ】： Source Address: Select “Outside_Any” Destination Address: Select “DMZ_Any” Service: Select “e-Mail” Action: Select “PERMIT ” Click OK 【DMZ to WAN】： Source Address: Select “DMZ_Any ”...
- Page 14 Mail Server is in WAN When Mail Server is in WAN, it does not need to set Mail Relay function. Only have to set up to Step13. (FigureS-11) FigureS-11 Mail Server in WAN...
