30W PORTABLE WORKLIGHT
Introduction
The Arlec WLED30 is suitable for
indoor and temporary outdoor use. It is
ideal for contractor, tradesman and DIY
handyman applications. Please note
that when used outdoors the supply
plug and socket-outlet must be suitably
protected against water ingress.
Use of Worklight
1 Adjust the tilt of the lamp head by
pushing the top of head forward
or backward to the desired position
while holding the stand firmly by
the handle.
2 Plug the worklight into a power point.
3 Turn on the power to the worklight.
Hold stand handle firmly
Push lamp
head forward
or backward to
desired angle
Important Notes
• Do not remove the support bracket
from the lamp body.
• Do not pinch or sharply bend the
supply cord while adjusting the
lamp head.
• Do not open the worklight body,
there are no user serviceable
parts inside.
• Do not immerse in water or any
other liquid.
• Do not use abrasive cleaners,
clean with a damp cloth.
• If the supply flexible cord is
damaged it must only be replaced
by a service agent or similarly
person in order to avoid a hazard.
30W PORTABLE WORKLIGHT
High Output LED
Module Array
• 30W LED array
• Provides high intensity even
light distribution
• Indoor/Outdoor lighting
for contractor, tradesman,
and DIY applications
• Cool to touch durable diecast
aluminium housing
• Wide angle coverage for large
work areas
• Weatherproof IP65 rating.
120°
even
light
beam
CPIN002816
Specifications
INPUT VOLTAGE 220-240Vac
50Hz
WATTAGE 30W
IP
IP65
CLASSIFICATION
LED Super bright module
• 1000mA
• 29-35V
• 30W
• 3000K
(non-replaceable type)
PROTECTIVE Glass Lens
SHIELD 222 x 181 x 3.85mm
thick
ENCLOSURE Zinc / Aluminium Alloy
